Sale B-398,B-399,Ardival, Aldrey or Almelec AAAC All aluminium alloy conductor
- 10000 Kilometer / Kilometers per Month
- FOB Qingdao Port or Other Chinese Port
- T/T Credit Card
- AY A108 Laser Radar FPC Cable Solves iPhone Camera Lag Problem
- 2.5/4/6mm red black solar cable 1500V DC solar cable awg PV solar panel cable
- New Design 4mm 6mm 10mm Tinned Copper Conductor DC Photovoltaic Solar pv Cable
- 2.5mm 4mm solar dc wire pv electric cable 6mm2 solar panel power cable H1Z2Z2-K photovoltaic solar extension wire
- electric power solar extension cable 6mm2 solar cable 4mm 10mm 16mm dc pv wire h1z2z2-k solar panel photovoltaic electric cable
- TUV pv solar cable Red 6mm PV1-F for solar panel collecting cable electric solar cable wire
Product Details
Place of Origin: | Henan, China | Brand Name: | Jinyuan | Model Number: | None |
Insulation Material: | Other, None | Type: | Other, low voltage, medium voltage and high voltage | Application: | Overhead |
Conductor Material: | Aluminum | Jacket: | Other, None |
Product Description
Zhengzhou Jinyuan Wire and Cable Co.,Ltd:
AAC All aluminium alloy conductors for American B-398/ B-399 Ardival, Aldrey or Almelec standard:
Detailed Product Description
Applications
Used as bare overhead conductor for primary and secondary distribution. Designed utilizing a high-strength aluminum alloy to achieve a high strength-to-weight ratio; affords better sag characteristics. Aluminum alloy gives AAAC higher resistance to corrosion than ACSR.
Construction
Standard 6201-T81 high strength aluminum conductors, conforming to ASTM Specification B-399, are concentric-lay- stranded, similar in construction and appearance to 1350 grade aluminum conductors. Standard 6201 alloy conductors are similar to other alloy conductors commercially known as Ardival, Aldrey or Almelec. They were developed to fill the need for an economical conductor for overhead applications requiring higher strength than that obtainable with 1350 grade aluminum conductors, but without a steel core. The DC resistance at 20°C of the 6201-T81 conductors and of the standard ACSRs of the same diameter are approximately the same. Conductors of the 6201-T81 alloys are harder and, therefore, have a greater resistance to abrasion than conductors of 1350-H19 grade aluminum.
Specifications
AAAC bare conductor meets or exceeds the following ASTM specifications :
B-398 Aluminum Alloy 6201-T81 Wire for Electrical Purposes
B-399 Concentric-Lay-Stranded 6201-T81 Aluminum Alloy Conductors.
Total Area | Overall Diameter | |
AWG or MCM | mm | mm |
6 | 13.3 | 4.65 |
4 | 21.1 | 5.88 |
2 | 33.6 | 7.41 |
0 | 53.5 | 9.36 |
2/0 | 67.4 | 10.50 |
3/0 | 85.0 | 11.79 |
4/0 | 107.2 | 13.26 |
250 | 126.7 | 14.55 |
300 | 152.0 | 15.95 |
350 | 177.3 | 17.25 |
400 | 202.7 | 18.45 |
450 | 228.0 | 19.55 |
500 | 253.4 | 20.60 |
550 | 278.7 | 21.70 |
600 | 304.0 | 22.61 |
650 | 329.4 | 23.59 |
700 | 354.7 | 24.43 |
750 | 380.0 | 25.34 |
800 | 405.4 | 26.11 |
900 | 456.0 | 27.72 |
1000 | 506.7 | 29.26 |
