Specifications
1. Easy to use and maintain,with the high rate of bander,big density2. Easy to storage.
3. Widely usage
Introduction
1.with the advantages of simple structure,durability,safe,easy to use and maintain,with the high rate of bander,big density ,it is widely used in the animal husbandry,paper industry,and the purchase and storage and transport of the wheat straw,straw,and pasture.
2.This machine can improve the safety degree of the stock ground,after packing,it can decrease the possibility of fire disaster,and not easy to fever ,spontaneous combustion, even the foreign flame lit ,it is also not easy to combustion
3.It is easy to storage ,if the same area of the straw,after packing ,it can save 67% of the area of the meadow.
4.It is convenient to load and unload and transport,it can make full use of the means of transport capacity,Generally it can improve the transport capacity 2-3 times,and can save more than 50% of the labour and transportation cost, it solve the problem of unsafety factors which is brought by the high, exceed wide
5.This cabinet can choose 18.5 KW motor or 25 to 30 horsepower engine for power according to user requirements.
Main structures
This machine mainly have motor or (diesel), reducer, gear, gear disk, small frame, connecting rod piston, swinging arm fork material system components and other parts, which is able to withstand the big of impact.
Main parameters
Model |
9YB2 |
Dimension |
7470*2660*2300mm |
Power |
18.5kw motor or 25-30 horsepower engine |
The running times of the piston |
34-40times/min |
Bale adjust length |
0.5-1.2m |
Weight |
3000kg |
Feeding |
0.67-0.84kg/times |
Capacity |
1600-2000kg/h |
Packing density |
≥100/m³ |
Pictures:
