sanitary standard flush pressure transmitter with flush diaphragm
USD $120 - $150
/ Piece
1 Piece(Min.Order)
- 5000 Piece / Pieces per Month
- TIANJING SHANGHAI SEAPOROT OR XI'AN AIRPORT
- Credit Card
You May Like
-
New 913A0124H01 York FRICK low-pressure pressure sensor, pressure range 0-200psi
-
New 913A0124H02 York FRICK high-pressure pressure sensor, pressure range 0-500psi
-
HBM S Type S9M Force Load Cell
-
HBM CFT+ Force Sensor
-
HBM C15 Force Transducer With 4MV/V Signal Output
-
HBM CFT Series Piezoelectric Force Transducer
Product Details
| Place of Origin: | Shaanxi, China | Brand Name: | QINWEI OR OEM | Model Number: | QWB105 |
Product Description
Sanitary standard flush pressure transmitter with flush diaphragm
Features:
Sanitary application
Without blockage in measuring
Piezoresistive silicon chip employed
MEMS technology
CE certificate
Specifications
| Pressure | |
| PressureRange | 35kpa, 70kpa, 100kpa,250kpa, 400kpa,600kpa, 1MPa, 1.6MPa, 2.5MPa, 4MPa,6MPa, 10MPa (bar and psi unit available) |
| Pressure Reference | Gauge pressure | Absolute pressure | Sealed gauge pressure |
| Overpressure | 300%F.S.(≤70kPa) | 200%F.S.( ≤10MPa) |
| Output Signal | |
| Output | 4-20mA | 0.5 to 4.5V |
| Performance | |
| Accuracy(including linearity, hysteresis and repeatability) | ±0.5%F.S. (Calibrated in vertical mounting position ) |
| Excitation | 24V | 5V |
| Compensated Temp. | -10-70ºC(typical) | -20-85ºC(available) |
| Ambient Temp. | -20-85°C |
| Media Temp. | -40-125°C |
| Storage Temp. | -40-125°C |
| Zero Temp. Coefficient | ±1.5%F.S.max.(-10-70ºC) |
| Span Temp. Coefficient | ±1.5%F.S.max.(-10-70ºC) |
| Pressure port | see last page "how to order" |
| Protection | IP65 |
| Housing material | Stainless steel 304 (SS316 for sensor inside) |
| Long-term Stability | ≤0.2%F.S./year |
| Weight | 280g(approx) |
We are a professional high tech enterprise that engaged in the development, sales and customized service of
Pressure sensors
Pressure transmitters,
Temperature sensors
Temperature transmitters,
Flow meters,
level measuring instruments,
Calibration instruments
Pressure gauges etc.
They are widely used inaerospace, automobile petroleum, chemical, metallurgy, Paper-making,
drugs manufacturing, electric power, food, medicine, railroad and water conservation etc industries
Any inquiry, contact us freely.
