70% IPA and 2%CHG swab ,CHG swab prep swab,surgical medical sterile swab

Specifications

CHG swab
1. the swab in the packing can be changed according to the customer's requirement
2. Certificates:Rohs,ISO13485



70% IPA and 2%CHG swab ,CHG swab prep swab,surgical medical sterile swab









1.Technical Introduction



CHGPrep Swab Stick FS707 with Large Rectangular Foam Tip.



Impregnated with 2% Chlorhexidine Gluconate (CHG) & 70% Isopropyl Alcohol (IPA) in clear solution.



 Prep Swab StickFS707large Rectangular foam tip is wash with 18 meg ohm D.I. water system in our Class 100 Cleanroom, going through drying process before it is impregnated with CHG antiseptic solution, individually pouch and pack.

Tear open the pouch at Notch, remove the handle from the pouch. Extra care must be taken not to touch the Foam Tip with finger to prevent cross contamination. Start to prep on the skin.

Characteristics:

1,Convenience of use



 2,No Glass and do not require activation before use. Easy handling



No need to wait for sponge to saturate

Eliminate the need for forceps, gauze swabs, bowls, and bottled solutions.

Tip made of medical grade 100 ppi, open cell polyurethane foam, soft, inert and hypoallergenic.

Non abrasive, latex free.

Foam is thermal sealed directly onto the plastic handle without use of adhesive make it more environmental friendly and RoHS Compliance.



For use : Patient preoperative skin preparation

CHGPrep Swab Stickused on preoperative skin antisepsis preparation for the following applications :-

Patient preoperative skin preparation prior to minor surgery

Patient pre-injection preparation ( Insertion of all types of catheters )



Swab Stick Technical Specification :



Foam tip material	100 ppi, open pore Polyurethane
Handle material	Medical Grade Polypropylene.
Handle dimensions(length x width x thickness)	Approximately 4.173” x 0.260 x 0.126” or 106 X 6.6 x 3.2 (in mm)
Foam tip dimensions(length x width x thickness)	0.984” x 0.591” x 0.346” or 25 x 15 x 8.8 (in mm)
Fill content	2% w/v CHG + 70% v/v IPA Antiseptic Solution
CHG Antiseptic Solution content	3.0 ml
Treatment Coverage Area ( in square inches )	4” x 4”

Handle Specification :

Part No.	Head Width	Head Thickness	Head Length	Handle Width	Handle Thickness	Handle Length	Total Swab Length	Packaging
FS707	15 mm (0.591")	8.8 mm (0.346")	25 mm (0.984")	6.6 mm (0.260")	3.2 mm (0.126")	106 mm (4.173")	131 mm (5.157")	50 swabs/box 20 boxes/case



Options :



Other Antiseptic Solution composition

It can be customized with the following formulation ratio content :-

1)       0.5% w/v CHG ( Chlorhexidine Gluconate ) + 70% v/v IPA ( Isopropyl Alcohol )



2)       3.15% w/v CHG ( Chlorhexidine Gluconate ) + 70% v/v IPA ( Isopropyl Alcohol )



3)       4.0% w/v CHG ( Chlorhexidine Gluconate ) + 70% v/v IPA ( Isopropyl Alcohol )





Available in clear or tinted solution

Packing:

















Packing : 50 Swabs/Box

Packaging : 50 swabs per box

Box Dimension (mm) : 170 X 100 X 107

Gross weight ( kg ) :0.35

Carton packaging  : 20 boxes of 50 swabs ; 1000 swabs per carton

Carton dimension (mm) : 350x210x555mm

Cubic volume (m3) : 0.041

Gross weight (Kg)  : 7.80
