High Speed Paper Cup Paper Bowl Punching Machine

High Speed Paper Cup Paper Bowl Punching Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Product Type:
Other, roll paper die cutting machine
Processing Type:
Cutting Machine
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Product Type Other, roll paper die cutting machine
Processing Type Cutting Machine
Place of Origin Zhejiang, China
Brand Name NEW DEBAO
Model Number ZDM-1
Power(W) 11kw
Dimension(L*W*H) 4000*1700*1700
Weight 6000kg
Certification CE
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

ZDM-1 Automatic indentation roll paper die-cutting machine
micro-computer, human-computer control interface
servo positioning

                       Welcome to Ask for ZDM-1 Automatic         Indentation Roll Paper Die-cutting Machine

high speed paper cup paper bowl punching machine







Product Description





 1.Description:

ZDM-1 Automatic indentation roll paper die-cutting machine adopts micro-computer,human-computer control interface, servo positioning,alternating curent frequency converter, automatic counting, manual pneumatic lock plate, photoelectric correcting deviation system,electromagnetic clutch,centralized oil lubrication,overload protection and distinctive gearing.

2. Main Technical Parameter

Die-cutting precision ±0.10mm
Rated  die-cutting rate 60-100 times/minute
Maximum die-cutting Rate 110 times/ minute 5400 times/ minute
Maximum die-cutting Rate pressure 120T
Maximum die-cutting Size 900×500mm/1000×500mm
Air supply requirement 0.5-0.6Mpa
Applicable paper type 135-500gsm(various roll of paper before or after printing)
Total power of electric machinery 11kw
Power of mainframe 7.5kw
Overall dimensions(L×W×H) 4000×1700×1700mm
Weight 6000kg
Conditions for using Draft, dry , suggested temperature for using:10-25°C
Roll paper size   Diameter≤1400mm   Width≤1000mm





 3. Working process:


high speed paper cup paper bowl punching machine



Cut From Paper rolls to paper blanks/fans/sheets.



high speed paper cup paper bowl punching machine

             4.Certificates

high speed paper cup paper bowl punching machine








Packaging & Shipping





 Packaging detail: Wooden case

 Delivery detail: 40 days







Packaging&Container:







high speed paper cup paper bowl punching machinehigh speed paper cup paper bowl punching machine















Our Services











Our company possess an excellent technical team for aftersall servie,which serve for each client.
