Sand And Dust Resistance Test Chamber
- 120 Unit / Units per Month
- Shanghai Guangzhou Dalian Tianjin Shenzhen HK
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Place of Origin: | Shaanxi, China | Brand Name: | LIB | Model Number: | DI-800 |
Power: | Electronic | Usage: | Universal Testing Machine |
Product Description
Sand And Dust Resistance Test Chamber
Sand And Dust Resistance Test Chamber
Main Technology Parameters
Model | DI-800 | DI-1000 | DI-1500 |
Workroom dimension (mm) | 800*1000*1000 | 1000*1000*1000 | 1000*1500*1000 |
External dimension (mm) | 1050*1420*1820 | 1250*1420*1820 | 1250*1900*1820 |
Performance index | |||
Metal mesh diameter | 50um | ||
Nominal spacing between lines | 75um | ||
The Talcum powder amount | 2kg ~ 4kg/m3 | ||
Fight time | 0 ~ 99H59M | ||
Fan cycle time | 0 ~ 99H59M | ||
Specimen power outlet | Dust-proof socket AC220V 16A | ||
Control system | |||
Controller | programmable Color Touch Screen Type | ||
Vacuum system | Equipped with a pressure gauge, air filter, pressure regulating triple,connecting tube ( Reprovision vacuum pump, which should be explained in detail when ordering) | ||
Circulating fan | Enclosed alloy low-noise motor, multi-vane centrifugal fan | ||
Dust heating system | Stainless steel mica sheet heating jacket | ||
Safety Devices | Electric leakage, short circuit, Overtemperature, motor overheating Overcurrent protection/ Power failure memory function for controller |
Test Area And Shelf
1. Is made of stainless-steel;
2. A shelf is located above the sieve and funnel, you can put test specimen on it;
3. Load of shelf is 50kg (If you need heavier load, please confirm with us);
Controller Panel
5.7'' programmable color touch display;
99 programs 99 sections;
R-232 interface;
PC Link with software;
Sand And Dust Resistance Test Chamber
Export Standard Wooden Package
Can be used for Sea, Air, Railway, Truck transportation.
3 Years Warranty
