Home > Products > Drilling spool&Adaptor Flange > oil field 13 5/8" 15000psi forging drilling spool
oil field 13 5/8" 15000psi forging drilling spool
- 60 Set / Sets per Month
- China mainland port
- T/T
Product Details
Condition: | New | Place of Origin: | Hebei, China | Brand Name: | Drilltech |
Model Number: | 13 5/8"-15000psi | Certification: | API6A, ISO9001 | Warranty: | 1year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
According to the requirements of customers
Product Description
Specifications
1.Forging Drilling spool2. Use: oil field
13 5/8" 15000psi forging drilling spool
1 API 16A Q1.
2 H2S Trim.
3 Adopt casting or forging
4 Drilling Spool
- According to the latest API Spec 16A standard,NACE MR-01- 75and quality standard of ISO9001.
- H2S Trim.
- the ring grooves flanges are all lined with the corrosion resistant alloy
- Bore:13 5/8”
Working pressure:15,000psi
Top connection:13 5/8”-15000psi 6BX BX159 SST Flanged
Bottom connection:13 5/8”-15000psi 6BX BX159 SST Flanged
Outlets:2×3 1/16”-15000psi 6BX BX154 SST Flanged
Weight:1700
Dimension:885×885×1000
Company Profile
Drilltech Manufacturing Co., LTD is a company focus on manufacturing Diverter(JACK-UP and Semi-submersible),Blowout preventer, Hydraulic disc brake and Automatic driller unit(VFD\SCR). We have API, ISO , ABS(American Bureau of Shipping), RMRS(Russian Register of Shipping) Lloyd's Register Classification Society(UK), Lloyd's Register Classification Society(Germany), Industrial and Engineering Inspection co of IRAN and the Russian Technical Supervision acceptance.
Contact Us
- Drilltech Manufacturing Co., Ltd. Cangzhou
- Contact nameJohn Qiu
- Phone86-317-3051105
- AddressThe north side of Beihuan Road,XinHua District,Cangzhou Cangzhou,Hebei
