Help Center2-Phase Stepper Driver Q2BYG806MD
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
ADTECH
Model Number:
Q2BYG806MD
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
3 Phase Hybrid Stepping Driver Q3BYG2207MCNegotiableMOQ: 1 Set -
QS7AA030M Signal Phase AC Servo Driver 220VNegotiableMOQ: 1 Set
-
2-Phase Stepper Drive Q2BYG806EMNegotiableMOQ: 1 Set
-
400W AC Servo Motor MRMS06040DNegotiableMOQ: 1 Set
-
2 Phase AC Servo Motor Driver QS7AA050M2NegotiableMOQ: 1 Set
Place of Origin
Guangdong, China
Brand Name
ADTECH
Model Number
Q2BYG806MD
Motor Type
Stepper Motor
Specifications
1)full digital hybrid stepper driver.2)high integration and CE certified.
3)high speed & high torque output,low vibration.
Q2-BYG806MD Stepper Driver Feature:
- can drive 4,6,8 line two-phase stepper motor
- super Low vibration and noise
- inside software Micro-subdivision technology, low speed&low subdivision can also achieve high subdivision results
- counter EMF compensation function,to maintain constant torque when speed increases
- Parameter self-adjusting function
- Current setting convenient,2.5A∼6.0A can be chosen freely.
- high subdivision precision,1-256 can be chosen freely.
- Impulse response frequency up to 200KHz...
- Serial communication function,real-time adjustable parameters to meet the high performance requirements
- with overvoltage,undervlotage, short circuit protection functions and so on.
Q2-BYG806MD Stepper Driver Parameters:
| input voltage | Single power DC24V-DC80V |
| overvoltage protection point | 45VDC |
| undervlotage protection point | 18VDC |
| phase current(A) | 2.5 3.0 3.5 4.0 4.5 5.0 5.5 6.0 |
| subdivision | 1,2,4,8,16,32,64,128, 256,5,10,25,50,100,200 |
| control mode | Impulse+direction |
| protection circuit type | Undervlotage, overvoltage and overcurrent protection |
| cooling type | nature air cooling | |
| operating environment | occasion | Avoid oil mist, metal dust and corrosive gases |
| environment humidity | 30%∼90% | |
| ambient temperature | 0°C∼50°C | |
| vibration | 5.9m/s2 max | |
| weight | 300g | |
| size | ||
Q2-BYG806MD Stepper Driver Applications:
Suitable For a variety of small and medium sized automation equipment and instruments, such as: dispenser, marking machine,cutting machine,engraving machine,labeling machine, plotter, automatic assembly equipment, numerical control machine and so on. Best effects In user expectations of low vibration, low noise, high-speed device applications.
