ACH-09075BC Middle-Inertia AC Servo Motor

Name: ACH-09075BC Middle-Inertia AC Servo Motor
Brand: ADTECH
SKU: 107842467
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

ADTECH

Model Number:

ACH-09075B

Type:

Servo Motor

ADTECH (Shenzhen) Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHENZHEN

Delivery Detail:

Delivery time depends on order quantity.

Brand Name ADTECH

Model Number ACH-09075B

Type Servo Motor

Output Power 750W

Certification CE

AC Voltage 208-230 / 240 V

Place of Origin Guangdong, China

Specifications

1.750W servo motor, 2000PRM/minute;
2.High speed and torque ac motor;
3.Low noise, low vibration,
4.Easy installation

ACH-09075B(750W) Middle-Inertia Servo Motor

Product Feature:

High speed and torque

Highly stable

Low noise, low vibration

High precision

Beautiful appearance, easy installation

High quality

AC Servo Motor ACH-09075B Technical parameters:

Motor model	ACH-09075B
Rated power (W)	750W
Rated rotation (r/min)	2000
Rated torque (N.m)	3.5
Maximum torque (N.m)	10.5
Rated line current (A)	3
Rated line voltage (V)	220
Rotor inertia (Kg.m²×10^-4)	3.4
Brake	---
Coder line number (PPR)	2500
Suitable drive model	QS5AA020M
Weight (Kg)	3.9
Insulation grade	B
Rating	Continuous
Ventilation protection	Completely sealed, self cooling
Installation mode	Flange (60, 90 110, 130)
Over-heating protection	None
Place, altitude and atmosphere	Indoor, lower than 1000m, no corrosive and inflammable gas, dust and oil mist
Ambient temperature and humidity	Environment temperature: -20°C ~+50°C; relative humidity: <90% (no condensing)
