3-axis PCI Laser Motion Control Card ADT-8937

Name: 3-axis PCI Laser Motion Control Card ADT-8937
Brand: ADTECH
SKU: 107840955

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

ADTECH

Model Number:

ADT-8937

ADTECH (Shenzhen) Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

FOBSHENZHEN

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name ADTECH

Model Number ADT-8937

Specifications

1.3-axis servo/step control, 32-bit PCI BUS, plug and play;
2.Support developing software with VC++,VB,BC++,LabVIEW,Delphi,C++

Feature

Apply super FPGA and high speed and precision of DA integrated circuit, which make high speed process and exact processing position;
Apply all optical coupling isolation technology, which makes machine stable and low-consumption;
3-axis servo/step control, 32-bit PCI BUS, plug and play;
The work power 5V is supplied by the main board while the digital signals I/O supplied by external power;
Supply 4 channels analog signal, 2 of the 4 are used for Galvanometer control while the rest 2 channels used to control laser power;
One channel switch signal for laser control, one suppression signal for first pulse, one channel PWM signal;
9 channels general digital output signal, 22 channels digital input signal;
Support DOS,Windows95/98/NT/2000/XP operation systems;
Support developing software with VC++,VB,BC++,LabVIEW,Delphi,C++Builder.

Function

1.Input of switch quantity

Channel 22 channels, all optical coupling isolation

Input voltage 4.5-5.5V

High level>3V

Low level<0.7V

Isolation voltage 2500V DC

The delay of optical coupling input is less than 0.1ms

2.Pulse input:

Channel 3 axes pulse,3 axes direction

Max pulse frequency 1MHz

Input mode pulse+direction or pulse+pulse
