Help CenterEthernet Motion Controller/stand-alone Controller ADT-8840(CE)
Related Products
Specifications
1) 4-axis servo/step 4-axis stand-alone controller2) I/O: 38/22
3) random 2-4 axes linear interpolation
4) support G code
ADT-8840 Four-axis Stand-alone Motion Controlleris a high performance and multifunctional motion control system. In hardware, it uses high speed microprocessor, large scale customized IC chip, multilayer printed circuit board, integrating the advantages of many domestic and foreign manufacturers. The hardware features high stability, perfect performance and maturation. It contains 4-line pulse/direction signal output, 4-axis coder AB + Z phase pulse input, 34-line optical coupling input + 4-line alarm input, 18-line optical coupling output + 4-line axis control output
Main characteristics.
ADT-8840 Four-axis Stand-alone Motion controller is a high performance and multifunctional motion control system. In hardware, it uses high speed microprocessor, large scale customized IC chip, multilayer printed circuit board, integrating the advantages of many domestic and foreign manufacturers. The hardware features high stability, perfect performance and maturation. It contains 4-line pulse/direction signal output, 4-axis coder AB + Z phase pulse input, 34-line optical coupling input + 4-line alarm input, 18-line optical coupling output + 4-line axis control output, 2-line RS232 communication modules, USB interface, and network interface. The description of this hardware functions follows.
1.Switching quantity input
Channel: 32, all optical coupling isolation
Input voltage: 5-24V
High level > 4.5V
Low level < 1.0V
Isolation voltage: 2500V DC
Optical coupling input delay: ≤0.1ms
2.Counting input
Channel: 4AB phase coding input, all optical coupling isolation (multiplexing with 8 input switching quantities)
Maximum counting frequency: 2MHz
Input voltage: 5-24V
High level > 4.5V
Low level < 1.0V
Isolation voltage: 2500V DC
3.Pulse output
Channel: 4-axis pulse, 4-axis direction, all optical coupling isolation
4-axis stand-alone controller
