HOT good quality coaxial cable RG6 1.02mm CU/CCS
| RG6 | STANDARD SHIELD | TRI-SHIELD | QUAD-SHIELD | ||||
| CONDUCTOR | MATERIAL | BC/CCS | BC/CCS | BC/CCS | |||
| Nom.Dia. | 18AWG=1.02mm | 18AWG | 18AWG | ||||
| DIELECTRIC | MATERIAL | Foam PE | Foam PE | Foam PE | |||
| Nom.Dia. | 4.57mm | 4.57mm | 4.57mm | ||||
| SHIELD | MATERIAL | Al foil+Al braiding | Al foil+Al braiding+Al foil | (Al foil+Al braiding)*2 | |||
| COVERAGE | 40%-95% | 40%-95% | 60%/40% | ||||
| JACKET | MATERIAL | PVC/PE | PVC/PE | PVC/PE | |||
| Nom.Thick | 0.80mm | 0.80mm | 0.86mm | ||||
| Nom.Dia. | 6.91mm | 7.06mm | 7.62mm | ||||
| Nominal Impedance(ohm) | 75±3 | ||||||
| Nominal Velocity of propagation(%) | 85 | ||||||
| Nominal Capacitance(pf/m) | 50 | ||||||
| Sparker Test(VAC) | 4000 | ||||||
| SRL(dB) | 20 | 20 | |||||
| Attenuation [68°F(20℃)] | Frequency(MHz) | Maximum(dB/100ft) | Maximum(dB/100ft) | ||||
| 5 | 0.58 | 1.9 | |||||
| 50 | 1.5 | 4.9 | |||||
| 100 | 2.0 | 6.5 | |||||
| 200 | 2.8 | 9.2 | |||||
| 400 | 4.1 | 13.6 | |||||
| 600 | 5.1 | 16.7 | |||||
| 700 | 5.6 | 18.4 | |||||
| 900 | 6.2 | 20.3 | |||||
| 1000 | 6.5 | 21.4 | |||||
Q1:Are you a factory or Trade company?
We are manufacturer, Welcome to visit us anytime. Thank you.
Q2:Where is your factory located? How can I visit there?
Our factory is located in Hangzhou City, ZheJiang Province, China.All our clients, from home or abroad, are warmly welcome to visit us!
Q3:What is the advantage in your company?
Reliable Quality:
----10 years cable experience with exquisite technology.
Favourable Price:
----Our factory located in a small town, which makes the labour cost lower.
----Long-term raw material suppliers and large purchasing of raw materials, which makes cost lower.
Q4:What is the after-sale service?
One year warranty and professional technology person to slove your matters.
Q5:Do your provide any sample?
Yes,we do pleasure to provide samples for your checking and testing.You soon feedback will be appreciated.
Q6:Could I play an small order quantity for the first order ?
Yes, We accept small order . It is easy for customer to make a test .
If any interested or further information about out products and services you would like to know , pls don't hesitate to send us an inquiry or contact us directly , We are glad to be of your service .
