Home > Electrical & Electronics > Optical Fiber, Cable & Wire > Communication Cable > You Can't Miss Good Quality75OHM RG6 CATV Cable

You Can't Miss Good Quality75OHM RG6 CATV Cable

Name: You Can't Miss Good Quality75OHM RG6 CATV Cable
Brand: yusheng
SKU: 107802147
Availability: InStock

You Can't Miss Good Quality75OHM RG6 CATV Cable thumbnail-1

You Can't Miss Good Quality75OHM RG6 CATV Cable photo-1

Negotiable MOQ: 50 Kilometers (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

yusheng

Model Number:

RG6/U

Contact Supplier Request Quote Chat Now

Hangzhou Yusheng Cable And Wire Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

any port inCHINA

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name yusheng

Model Number RG6/U

Type Coaxial

Number of Conductors 1

Specifications

1.75Ohm High-End Coaxial Cable for Video,Analog & Monitor Applications
2.Good quality
3. Factory price
4. RG6

Packaging & Delivery

Packaging Detail:	Packing: 1. Packing length: 100m/ roll, 200m/ roll, 305m/ roll, 100yard/ roll, 200yard/ roll, 200yard/ roll, 300yard/ roll, and other length available according to clients' request. 2. Inner packing: wooden reel, plastic reel, paper reel available. 3. Outer packing: Carton box, pull out box, pallet available.
Delivery Detail	10~15 days

Specifications

1.75Ohm High-End Coaxial Cable for Video,Analog & Monitor Applications
2.Good quality
3. Factory price
4. RG6

specification
RG6:
Conductor: 1.02mm BC or CCS
Dielectric: 4.57mm or 4.80mm Foam PE
Shield: Al Foil
Braiding: Al-Mg 45-90%
Jacket: 6.80mm to 7.00mm PVC

Coaxial cable RG6:
1. Center conductor: BC, CCS, TC and CCA available.
2. Al-foil: Non-bonded Al-foil, bonded Al-foil, double bonded Al-foil, double non-bonded Al-foil.
3. Braiding wire: Al-Mg, BC, CCS, CCA and TC available.
4. Braiding wire diameter: 0.10, 0.12, 0.13, 0.14, 0.15, 0.16mm available.
5. Braiding net: 32, 48, 64, 80, 96, 120, 128, 144 and more available.
6. Braiding coverage: between 30-97% available.
7. Jacket: PVC, PVC.

test results:
    Impedance: 75±3Ω
    Echo return loss:
      VHF: 22.2dB
      UHF: 24.3dB
    Attenuation:
      5MHz: 2.18dB/100m
      50MHz: 4.51dB/100m
      200MHz: 8.32dB/100m
      550MHz: 14.08dB/100m
      800MHz: 17.31dB/100m
      1,000MHz: 18.96dB/100m
    Insulation resistance: 5,000MΩ/km
Purposes: CATV networks, television and SAT TV
Certificates: SARFT, ISO9001, CCC, CE and RoHS
