Specifications
DFR Computer Heat-sealing & Heat cutting bag making machineApplication:
This machine is suitable for heat-sealing and thermal cutting of such plastic films as LDPE and HDPE, etc. And it is a kind of ideal equipment for specially producing vest bags of natural color and multicolor.
Performance and Characteristics:
1.Thermal cutting device with new style design,easy and fast pressure adjustment of sealing and cutting knife, 180 integral turnover,easy clearing and replacing of glue cloth.
2.Imported reflecting photoelectric switch monitoring,stable and reliable feeding,automatically stopping the machine when the color mark is lost.
3.The whole machine adopts microcomputer control,material-pulling by stepping motor(which can be equipped with servomotor control system),accurate sealing and cutting size.
4.Automatic counting and settable counting alarm and whole copy output system.
5.Imported variable frequency motor makes the equipment stable and electricity-saving.Centralized Oil Supply System
Main technical variables:
| Type | DFR 500 | DFR600 |
| Max.Cutting Width | 450mm | 550mm |
| Cutting Length | 800mm | 850mm |
| Cutting Thickness | 0.0080---0251mm | 0.0080---0251mm |
| Capacity | 30---120/pc | 30---120/ pc |
| Total Power | 4Kw | 4.5Kw |
| Weight of Machine | 800kg | 900kg |
| Overall Dimension | 2800×1060×1350mm | 2800×1160×1350mm |
