Specifications
It is suitable for heat-cutting & heat-sealing all kinds of natural color films and color films such as: BOPP, OPP, PE etc. It cBOPP OPP PE bag making machine
Characteristic:
1.The main motor adopts frequency conversion motor to adjust the speed .
2.It adopts microcomputer to control, servo motor to pull material,which will accurate the sealing and cutting location .Automatic counting and settable counting alarm .The machine will stop automatically when the color mark is lost.
3.Feeding by DC motor and film potentiometers add the synchronization between feeding and main motor .
4. The sealing and cutting blade is a kind of special tool steel ,uneasy deformation .
5.The conveyor belt adpots the imported driven strap and DC motor to adjust the speed ,which make the process of receiving bags steady and reliable .
6.It adopts pneumatic equipment to punch. Rubberizing simultaneously.
Main Technical Parameters:
Model MTBF-650
Producing bag Length100-600
Producing bag Width:50-1000mm
Thickness of Film0.01-0.10mm
Producing Speed30-140 (pcs/min)
Main Power5kw
Power Source220V 50Hz
Weight1100kg
Overall Dimensions (L*W*H)5000*1250*1850mm
Packing Dimensions (L*W*H):3000*1400*2050mm
Model MTBF-800
Producing bag Length:150-750mm
Producing bag Width:70-1000mm
Thickness of Film:0.01-0.10mm
Producing Speed:30-120 (pcs/min)
Main Power:5kw
Power Source:220V 50Hz
Weight:1300kg
Overall Dimensions (L*W*H):5000*1400*1850mm
Packing Dimensions (L*W*H):3000*1500*2050mm
Model MTBF-1000
Producing bag Length:150-950mm
Producing bag Width:80-1000mm
Thickness of Film:0.01-0.10mm
Producing Speed:30-100 (pcs/min)
Main Power:5.5kw
Power Source:220V 50Hz
Weight:1400kg
Overall Dimensions (L*W*H):5000*1600*1850mm
Packing Dimensions (L*W*H):3300*1670*2050mm
Optional equipment :
(1)Puncher
(2) conveyor
(3) yaskawa or panasonic servo motor
(4)gusset
(5)E.P.C
