SMTSEC SVC-C-361 Color Video PTZ Web Video Conferencing System Camera

SMTSEC SVC-C-361 Color Video PTZ Web Video Conferencing System Camera thumbnail-1
SMTSEC SVC-C-361 Color Video PTZ Web Video Conferencing System Camera thumbnail-2
SMTSEC SVC-C-361 Color Video PTZ Web Video Conferencing System Camera thumbnail-3
SMTSEC SVC-C-361 Color Video PTZ Web Video Conferencing System Camera photo-1
SMTSEC SVC-C-361 Color Video PTZ Web Video Conferencing System Camera photo-2
SMTSEC SVC-C-361 Color Video PTZ Web Video Conferencing System Camera photo-3
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Audio Conference System, Network Conference System, Video Conference System
Function:
Other, video conference camera
Simultaneous Interpretation:
No
Contact Supplier Request Quote Chat Now
Shenzhen Smart Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Audio Conference System, Network Conference System, Video Conference System
Function Other, video conference camera
Simultaneous Interpretation No
Place of Origin Guangdong, China
Brand Name SMTSEC
Model Number SVC-C-361

SMTSEC SVC-C-361 Color Video PTZ Web video conferencing system Camera

Product Description
SVC-C-361 Color Video PTZ Camera which adopted fixed lens with high performance 480 TVL CCD Quality, it equipped with AV video video output, ideally suited for Web video conferencing system, remote education system etc.
Model SVC-C-361
Image CCD 1/3" SONY CCD
Sensor Minimum Scene Illumination 0.5 Lux
White Balance AUTO/Manual
Gain Control Auto
Back-light Compensation On/Off
Electronic shutter 1/50-1/10,000s
Horizontal resolution 480 TVL
S/N Ratio > 50dB
Lens Focus AUTO
Iris AUTO/Manual
Zoom /
6mm fixed lens
Video Output VIDEO VBS 1.0Vpp at 75ohm;
/
Communication EIA/RS-422
EIA/RS-232(Bidirectional)
Baud Rate 2400/4800/9600 bps
Patrol tours 4
Pattern tours 4
Preset 64
Privacy Mask Zone 4
Power On Active Auto pan scan or Patrol(Programmable)
Speed Matching Function Support
OSD Menu Support
Image Auto Flip Support
Pan Speed 0-280 degrees/s
Tilt Speed 0-100 degrees/s
Pan rotation angle 360 degrees continuously
Tilt rotation angle 180 degrees
Auto Pan Scan Support
Boundary Scan 0-359 degrees(programmable)
Remoter Control IR Wireless remote control P/T/Z(10M)
Power DC 12V+-10%; 1.2A
Temperature and humidity 0°-60°C, 0-95% RH(non-condensation)

SMTSEC Video conference camera FAQ
Symptom Cause Remedy
The power of the camera is not turned on. The supplied AC power adaptor is not connected to the DC IN 12V jack firmly, or the AC power cord is not inserted firmly into the AC power adaptor or the AC outlet. Insert the power cord firmly as far as it will go.
Not Turn On the Power switch as “ON”. Turn On the Power switch as “ON”.
Insufficient frame rate detected Cannot recognize USB 3.0 connection, but the USB 2.0 speed. Make sure you connected USB 3.0 Cable, USB 3.0 connect, and firmly connect to USB 3.0 interface.
Pan,tilt or zoom cannot be operated. Any menu is displayed on the monitor screen. Press the “Dome OSD” OR “Lens OSD” on the Camera remote control Unit to turn off the menu from the monitor screen.
The panning or tilting range is limited Pan/Tilt movement range is ± 45 degree.
The Remote Commander does not work. The Camera Select button you pressed on the Remote Commander does not match the number set with the IR SELECT switch on the camera. Press the Camera Select button corresponding to the IR SELECT SWITCH setting on the Camera.
Used out of battery Change new battery (AA x 2)
The VISCA control is not available with a computer connected to the camera. The computer is not correctly connected to the camera. Make sure the connection between the computer and camera is made correctly.
Check that the VISCA control setting (RS-232C or RS-422) and the baud rate setting (9600 bps or 38,400 bps) are properly made with the BOTTOM switch on the bottom of camera and the COM Port which configured in your computer.
The camera cannot be operated at all. Pull out the plug of the power cord from the AC outlet, then reinsert it into the AC outlet after a while.



SMTSEC SVC-C-361 Color Video PTZ Web video conferencing system CameraSMTSEC SVC-C-361 Color Video PTZ Web video conferencing system CameraSMTSEC SVC-C-361 Color Video PTZ Web video conferencing system Camera



Packaging & Shipping



China Post (10-30 days)
EMS (5-15 working days)
DHL (3-5 working days)
UPS (3-5 working days)



•The most reliable, affordable way of shipping method deponds on your address.
•Online tracking number will be emailed to buyer through email.
•We dont take any responsibility for any custom delay.



Our Services



•All products have been checked and packaged in good condition before dispatch.

•All products have 1 year warranty.

SMTSEC SVC-C-361 Color Video PTZ Web video conferencing system CameraSMTSEC SVC-C-361 Color Video PTZ Web video conferencing system CameraSMTSEC SVC-C-361 Color Video PTZ Web video conferencing system CameraSMTSEC SVC-C-361 Color Video PTZ Web video conferencing system CameraSMTSEC SVC-C-361 Color Video PTZ Web video conferencing system Camera





 SMTSEC SVC-C-361 Color Video PTZ Web video conferencing system Camera
