LAMP super slim screen for sports

Specifications

super slim screen
1.Perfect image&video quality
2.High refresh rate
3.Unique structure design
4.Extreme viewing angle

Super slim screen



Main Features

1.Full color sports perimeter broadcasting display is specially designed for the sports stadium.

2.It’s optimized for advertising and broadcast.

3.Inimitable soft rubber cover is used for protecting both players and LED screen.

4.Easy fo installation and dismantle.

5.Soft rubber front surface to protect players.

6.High brightness and adjustable.

7.Folding supporting structure design.

8.Other indoor&outdoor play grounds.



Specification



Pixel Pitch:	10 mm
Pixel Density:	10000 pixels/sqm
Pixel Configuration:	SMD 3 in 1
Module Dimension:	160*160 mm
Module Resolution:	16*16 pixels
Cabinets Dimension:	800*640 mm
Cabinets Resolution:	80*64 pixels
Brightness:	5000 cd/sqm
Best Viewing Distance:	> 10m
Average Consumption:	344 W/sqm
Max Consumption:	860 W/sqm
Viewing Angle:	Horizontal angle: 140 degree Vertical angle: 140 degree
Processing:	12 bit
Ingress Protection:	Front IP65; Rear IP54
Refresh Rate:	600 ~ 4800Hz
LED lifetime:	100,000 hours
Input Voltage:	90 ~ 260VAC,50/60Hz
Operation Humidity:	10% ~ 99%





System Diagram



Solutions



All product specifications are for reference only and subject to change without prior notice; Please contact sales for details.

At the same time, we can design according to customer requirements and production.
