5050 led panel
Features:
1, solid aluminum structure to meet the requirements of thousands time of assemble and disasemble.
2, easy hanging structure support fast installation.
3, 14-bit color processing enable a vivid color quality.
4, 1000HZ refresh rate meet all your needs for broadcasting.
5, top industrial power and data connector from Neutrik enhance the stability for whole system.
6,total solution includes video processor, rental power distribution unit, truss...etc.
Specification:
| Pixel Pitch: | 10 mm |
| Brightness: | 7800 cd/sqm |
| LED Configuration: | SMD 3 in 1 |
| Pixel Density: | 10000 pixels/sqm |
| Viewing Angle(Vertical): | 140° |
| Viewing Angle(Horizontal): | 140° |
| Recommended Viewing Distance: | >10 m |
| LED Lifetime: | 100,000 hours |
| Power Consumption(Maximum): | 1000 W/sqm |
| Power Consumption(Average): | 500 W/sqm |
| Processing: | 12 bit |
| Refresh Rate: | 1200Hz |
| Scan Mode: | 1/2 scanning |
| Input Voltage: | 90 to 260VAC,50/60Hz |
| Cabinet Material: | Die-cast Aluminum |
| Protecting Louver: | Aluminum |
| Weight: | 9.5 kg/cabinet |
| Mounting: | Rigging |
| Max Rigging Load: | 12 cabinets |
| Cabinet Dimension(W*H*D): | 480*480*50 mm |
| Cabinet Resolution: | 48*48 pixels |
| Load Weight On Surface: | Not Applicable |
| Humidity Range: | 10% to 99% |
| Protection Rating: | Front IP65; Rear IP54 |
| LED Processor | DBSTAR |
| Controlling Distance: | 100m via CAT05/Maximum 10km via Fiber Optic(Single mode) |
| Signal: | DVI upto UXGA,SDI, HD-SDI, HDMI,S-video(Via Video processor) |
All product specifications are for reference only and subject to change without prior notice; Please contact sales for details
At the same time, we can design according to customer requirements and production.
System Diagram
