P10 P16 Outdoor DIP Tri-color Rental LED Video Wall for Concert Touring
led video wall
More advantages of our product as below:
1. Super light cabinets
A lighter aluminium cabinet makes it ideal for setup and teardown as well as transportations.
2. Easy rigging system
Each cabinet contains a strong rigging system to enable easy rigging and adjustments. Unique
latching device can keep all display panels on same horizontal line, it also keep the panel as a whole
without any aperture.
3. Standard industry components
We use industry standard power and data connectors from Neutrik to ensure the system reliability
and reduce the replacement cost.
4. State-of-art video processing and broadcasting standard
Provide 14bit image processing of colors resulting in a crystal clear picture with true-to-life color
reproduction; meet industry top quality requirement, high refresh rate, super image quality,
color uniformity and high contrast ratio.
Specification
| Pixel Pitch: | 10 mm | 16 mm |
| Pixel Density: | 10000 pixels/sqm | 3096 pixels/sqm |
| Pixel Configuration: | 1R1G1B | 2R1G1B |
| Module Dimension: | 160*160 mm | 256*128 mm |
| Module Resolution: | 16*16 pixels | 16*8 pixels |
| Cabinets Dimension: | 640*640 mm | 1024*768 mm |
| Cabinets Resolution: | 64*64 pixels | 64*48 pixels |
| Brightness: | 5800 cd/sqm | 7500 cd/sqm |
| Best Viewing Distance: | > 10m | > 16m |
| Average Consumption: | 450 W/sqm | 500 W/sqm |
| Max Consumption: | 900 W/sqm | 1250 W/sqm |
| Viewing Angle: | Horizontal angle: 120 degree Vertical angle: 60 degree | |
| Processing: | 12 bit | |
| Ingress Protection: | Front IP65; Rear IP54 | |
| Refresh Rate: | >600Hz | |
| LED lifetime: | 100,000 hours | |
| Input Voltage: | 90 to 260VAC, 50/60Hz | |
| Operation Humidity: | 10% to 99% | |
System diagram
Related solutions
LAMP’s outdoor rental LED display product ranges from pixel 10mm to pixel 40mm, IP65 rated outdoor display products that deliver high-resolution full color images with unequalled brightness and contrast levels. The product ranges offer a modular outdoor display concept that allows the build-up of almost any shape and size display that is ideal for use at rental marketing demand.
