LAMP indoor led background wall screen

Specifications

led background wall screen
1.Cambered cabinets design panel.
2.Vivid indoor video display panel.
3.90+countries experience

led background wall screen

Main Features

1.solid aluminum structure to meet the requirements of thousands time of assemble and disasemble.

2.easy hanging structure support fast installation.

3.14-bit color processing enable a vivid color quality.

4.1000HZ refresh rate meet all your needs for broadcasting.

5.top industrial power and data connector from Neutrik enhance the stability for whole system.

6.total solution includes video processor, rental power distribution unit, truss...etc.



Specification



Pixel Pitch:	7.62 mm
Pixel Density:	17200 pixels/sqm
Pixel Configuration:	SMD 3 in 1
Module Dimension:	488*244 mm
Module Resolution:	64*32 pixels
Cabinets Dimension:	488*488*94.87 mm
Cabinets Resolution:	64*64 pixels
Brightness:	3000 cd/sqm
Best Viewing Distance:	> 8m
Average Consumption:	450 W/sqm
Max Consumption:	950 W/sqm
Viewing Angle:	Horizontal angle: 140 degree Vertical angle: 140 degree
Processing:	12 bit
Ingress Protection:	IP20
Refresh Rate:	1200Hz
LED lifetime:	100,000 hours
Input Voltage:	90 to 260VAC, 50/60Hz
Operation Humidity:	10% to 99%



System Diagram

Related solutions





Certifications



Shenzhen LAMP Technology co., LTD has been recognized as one of the fastest growing and leading manufacturers in LED industry since its foundation in 2004 in Shenzhen, China. As a manufacturer and engineering contractor, LAMP provides standard display products as well as custom-designed systems for large screen video displays . The acquirement of the ISO9001:2008 Quality Control System and certificates such as ETL, CE, RoHs, etc, has guaranteed that LAMP runs under a strict and effective quality control system. Equipped with state-of-the-art equipment sourced from Germany and Japan, the newly established laboratory has also enhanced our quality test to a higher level.



Application

1. Stage venues

2. Entertainment venues

3. Sports arenas

4. Commercial advertising
