Home > Transportation > Forklifts & Parts > Forklift > 1.5t 1.8t 2.t 2.5t 3.0t 3.5t Baoli Forklift Truck

1.5t 1.8t 2.t 2.5t 3.0t 3.5t Baoli Forklift Truck

1.5t 1.8t 2.t 2.5t 3.0t 3.5t Baoli Forklift Truck thumbnail-1
1.5t 1.8t 2.t 2.5t 3.0t 3.5t Baoli Forklift Truck photo-1
US$ 7,000 - 20,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
Baoli
Contact Supplier Request Quote Chat Now
KION Baoli (Jiangsu) Forklift Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Jiangsu, China
Brand Name Baoli
Model Number CPC/Q/YD15-35
Type Powered Pallet Truck
Power Souce Other, Diesel/gasoline/LPG gas powered engine
Rated Loading Capacity 1500-3500kg
Max. Lifting Height 2500-6500mm
Min. Lifting Height 140mm
Fork Length 920-2120mm
Fork Width 100-130mm
Overall Dimensions 2255-2814mm
Certification CE, ISO9001, ISO14001
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Rated capacity(kg):1500-3500
Max lifting height(m):2.5-6.5m
Made in Chinese cost,Control at German standard
CE. ISO9001/14001

Baoli advantages and detailed specifications:

Rated capacity(kg):1500-3500
Max lifting height(m):2.5-6.5m
Made in Chinese cost,Control at German standard
CE. ISO9001/14001



Manufacturer   KION Baoli
Model   CPC(D)10 CPC(D)15 CPC(D)18
CPQ (D)10 CPQ(D)15 CPQ(D)18
CPY(D)10 CPY(D)15 CPY(D)18
Power type   Diesel/ Gasoline/ LPG
Rated capacity kg 1000 1500 1750
Load center mm 500
Lift height mm 3000
Free lift height mm 162
Fork size mm 920×100×40
Mast tilt angle deg 6/12
Front overhang mm 429
  Length to fork face mm 2180 2235 2270
Overall Overall width mm 1080
dimension Mast lowered height          mm 1995
  Mast extended height        mm 4042
  Overhead guard height      mm 2075
Turning radius mm 1890 1960 2000
  Hydraulic km/h 13.5/14.5
Travel speed Mechanical ShiftⅠ 5.5/6
( full load/no load) ShiftⅡ 13.5/14
Lift speed(no load/full load) mm/sec 510/450
Max. grade ability % 20
Self weight kg 2340 2740 2943
  Front   6.50-10-10PR
Tyre Rear   5.00-8-8PR 5.00-8-10PR
  Front mm 890
Tread Rear mm 920
Wheelbase mm 1400
  Mast        mm 95/110 85/110
Ground clearance(full load/no load) Frame        105/115

  Type Diesel engine Gasoline engine
  Model NB485BPG   Yanmar 4TNE92 ISUZU C240PKJ MITSUBISHI 4G64
  Rated output( kw/rpm) 30/2600   32.8/2450 34.5/2500 37/2500
  Rated torque (N.m/rpm) 131/1800   149/1600 139/1800 161/1600
  No. of cylinder 4   4 4 4
  Bore×stroke(mm) 85×100   92×100 86×102 86.5×100
  Displacement( L) 2.27   2.659 2.369 2.35
  Truck model CPC(D)10/15/18-X   CPC(D)10/15/18-Y CPC(D)10/15/18-W CPQ(Y)D10/15/18-M
Manufacturer   KION BAOLI FORKLIFT TRUCK
Model   CPC(D)20 CPC(D)25 CPC(D)30 CPC(D)35
CPQ(Y)D20 CPQ(Y)D25 CPQ(Y)D30 CPQ(Y)D35
Power type   Diesel/ Gasoline / LPG
Rated capacity kg 2000 2500 3000 3500
Load center mm 500
Lift height mm 3000
Free lift height mm 140 145 145
Fork size mm 1070×120×40 1070×120×45 1070×125×45 1075×130×45
Mast tilt angle deg 6/11
Front overhang mm 479 484 494 500
  Length to fork face mm 2510 2580 2720 2775
Overall Overall width mm 1150 1225
dimension Mast lowered height mm 2060 2080 2230
  Mast extended height mm 4040 4273
  Overhead guard height mm 2060 2090
Turning radius mm 2170 2240 2460 2540
Travel speed ( full load/no load) Hydraulic km/h 17/19 18/19
Mechanical Shift Ⅰ km/h 8.5 / 9 8.8 / 9
Shift Ⅱ km/h 18.5 /1 9 18.5/20
Lift speed with load mm/sec 470 430 400
Max. grade ability % 20 15
Service weight kg 3550 3880 4380 4750
  Front   7.00-12-12PR 28×9-15-12PR 28×9-15-14PR
Tyre Rear   6.00-9-10PR 6.50-10-10PR
  Front mm 970 1000
Tread Rear mm 970 970
Wheelbase mm 1650 1700
  Mast mm 85/105 120 / 145
Ground clearance
(full load/no load) Frame 115/120 135 / 140
Type Diesel engine Gasoline engine
Model Xinchang Xinchang Xinchang ISUZU Yanmar Yanmar Mitsubishi
BPG490 BPG495 BPG498 C240PKJ 4TNE92 4TNE98 4G64-31ZG
(kw/rpm) 37/2650 42/2650 45/2500 34.5/2500 32.8/2450 44.3/2300 37/2500
Rated output
(N.m/rpm) 148/1900 174/1800 191/1600 139/1800 149/1600 206/1700 161/1600
Rated torque
No. of cylinder 4 4 4 4 4 4 4
(mm) 90×100 98×105 98×105 86×102 92×100 98×110 86.5×100
Bore×stroke
(L) Displacement 2.54 2.98 3.168 2.369 2.659 3.319 2.35
Truck model CPC(D CPC(D) CPC(D) CPC(D) CPC(D) CPC(D) CPQ(Y)D
20/25/30-X1 30/35-X2 30/35-X3 20/25/30-W1 20/25-Y1 30/35-Y2 20/25/30-H1





 1.5t 1.8t 2.t 2.5t 3.0t 3.5t baoli forklift truck1.5t 1.8t 2.t 2.5t 3.0t 3.5t baoli forklift truck









About KION BAOLI:

KION Baoli develops, manufactures, distributes and services forklift trucks. As a brand of KION Group, Baoli focuses on the global economy market segment. Since 210 Baoli has been fully integrated and managed by KION Group. The Baoli factory located in Jingjiang(near Shanghai) manufactures a modern and complete electric, IC and warehousing truck range.

1.5t 1.8t 2.t 2.5t 3.0t 3.5t baoli forklift truck



Factory Gallery:

1.5t 1.8t 2.t 2.5t 3.0t 3.5t baoli forklift truck



Quality communications between Baoli and customers

1.5t 1.8t 2.t 2.5t 3.0t 3.5t baoli forklift truck



Baoli at the exhibitions

1.5t 1.8t 2.t 2.5t 3.0t 3.5t baoli forklift truck



Industry certificates:

1.5t 1.8t 2.t 2.5t 3.0t 3.5t baoli forklift truck









Send Inquiry to This Supplier

Message
0/5000

Want the best price? Post an RFQ now!
KION Baoli (Jiangsu) Forklift Co., Ltd.
Business Type
Manufacturer, Trading Company
Year Established
2008
Factory Size
Above 100,000 square meters
Total Employees
501 - 1000 People
