Hot Sell ACR122U 13.56 Mhz USB Interface Rfid NFC Card Reader & Writer with Free SDK
Our company sell the Sp-ACR122U rfid rfid & nfc writer and reader is a PC-linked contactless smart card reader/writer developed based on the 13.56 MHz Contactless (RFID) Technology.
Why choose us? hot sell ACR122U 13.56 Mhz USB interface rfid nfc card reader & writer with free SDK
Compliant with the ISO/IEC18092 standard for Near Field Communication (NFC), it supports not only ® and ISO 14443 A and B cards but also all four types of NFC tags.
The proximity operating distance of ACR122U is up to 5 cm, depending on the type of contactless tag in use.
In order to increase the security level, ACR122U can be integrated with an ISO 7816-3 SAM slot.
Furthermore, the ACR122U NFC Reader is available in module form, permitting easy integration into bigger machines, such as POS terminals, physical access systems and vending machines.
Other applications of the ACR122U include access control, e-payment, e-ticketing for events and mass transit, toll road fare collection and network authentication.
Features:
- CCID-compliant
- PC/SC-compliant
- Read/write speed up to 424 kbps
- Built-in antenna for contactless tag access, with card reading distance of up to 50 mm (depending on tag type)
- Supports ISO 14443 Type A and B, FeliCa, and all 4 types of NFC (ISO/IEC 18092) tags
- Built-in anti-collision feature (only 1 tag is accessed at any time)
- User-controllable bi-color LED
- User-controllable buzzer
Application:
- e-Government
- e-Banking and e-Payment
- e-Healthcare
- Transportation
- Network Security
- Access Control
- Loyalty Program
Tech Specs:
Dimensions |
98 mm (L) x 65 mm (W) x 12.8 mm (H) |
Weight |
70 g |
Interface |
USB Full Speed |
Operating Distance |
Up to 50 mm (depends on the tag type) |
Supply Voltage |
Regulated 5V DC |
Supply Current |
200mA (operating); 50mA (standby); 100mA (normal) |
Operating Temperature |
0-50 °C |
Operating Frequency |
13.56 MHz |
Smart Card Interface Support |
|
Compliance/Certifications |
|
Operating System Support |
|
Pictures of Hot Sell ACR122U 13.56 Mhz USB Interface Rfid NFC Card Reader & Writer with Free SDK:
Chois Enteprise Ltd. is a professional wholesaler and manufacturer of card printing systems and identification solutions. Established in 2010, we have years of experience in the ID industry. The Primacy product we provide including card Printer, printer ribbon, PVC cards, lanyard, card holder and related products.
With a huge selection of the popular brands in identification solution industry, we are your one-stop shop for providing you the high quality products with competitive cost, fast delivery & dedicated service. Located in Shenzhen, we also enjoy convenient water, land and air transportation.
We looking forward to cooperate with more customers for mutual development and benefits. We welcome potential buyers to contact us!
Which card printer is suitable to me?
If you don’t have given option, please provide our sales team a picture of the card (double side) you want to print. We will recommend you the most suitable model according to the printing need.
Which ribbon should I choose for my card printer?
If you don’t know the model number of your ribbon, please provide us the model number or picture of your card printer, our sales team will check and confirm it for you.
