ACS ACR1281U-C1 Dual-Interface Smart Card Reader, IC Card Reader
Overview
- The nPA (neuer Personalausweis) is a contactless electronic smart card ID that provides German citizens security for online identity and transactions, such as e-government, online shopping and online banking. ACS's ACR1281U nPA contactless reader is one of the world’s earliest nPA scheme-qualified readers that supports contactless extended APDU (Application Protocol Data Unit) command.
- The ACR1281U nPA contactless reader can access virtually any contactless smart cards following ISO 14443 standard. With its MCU's high processing speed and good antenna performance, it is ready for high speed and highly demanding applications, such as government qualifications including Germany's BSI (Federal Office for Information Security) certificate.
- The support for contactless extended APDU command makes the processing of large data in a much shorter period of time using ACR1281U nPA contactless reader than similar readers. Hence, ACR1281U nPA contactless reader is suitable for highly secure Public Key Infrastructure (PKI) algorithms, such as digital signatures on official documents utilizing 2,048 bits or 4,096 bits RSA keys; as well as the reading and writing of large files, such as photos and fingerprint images. At such speeds, users are able to experience the total satisfaction of utilizing contactless card technology.
- USB connectivity of the ACR1281U nPA contactless reader securely connects the contactless smart cards, such as the new Germany nPA e-ID cards, to any PC running on Windows, Mac or Linux operating systems. With a secure firmware upgrade capability, the reader is forward compatible with new card or functionality requirements.
- Following its certification, ACR1281U nPA contactless reader can now be readily deployed by government authorities, companies and other institutions for citizens to assess this nPA electronic ID card system, implemented by Germany’s Federal Ministry of the Interior.
Feature
- Germany BSI compliant
- CCID Compliant
- PC/SC Compliant
- Read/write speed up to 848kbps
- Supports major Contactless smart cards technologies such as ISO14443 Type A and B and series
- Card operating distance of up to 50 mm
- German eID card operating distance of up to 40 mm (eID card requirement)
- Support contactless extended APDU commands
- Firmware Upgradable
- USB Full Speed (12 Mbps)
- Support contactless memory cards such as SRI(X)4k cards (Upon request)
- In-device AES / 3DES encryption algorithm (Upon request)
Specification
Dimensions |
120.5 mm (L) x 72 mm (W) x 20.4 mm (H) |
Weight |
150g |
Interface |
USB 2.0 Full Speed |
Operating Distance |
Up to 50 mm (depends on the tag type) |
Supply Voltage |
Regulated 5 V DC |
Supply Current |
200mA (max); 100mA (normal) |
Operating Temperature |
0-50°C |
Humidity |
10 - 80 % |
Operating Frequency |
13.56MHz |
Smart Card Interface Support |
|
Compliance/Certifications |
Germany nPA certified, PC/SC, CCID, CE, FCC, RoHS Compliant, Microsoft WHQL: 2000, XP, Vista, 7 |
Operating System Support |
|
Application
- e-Government
- e-Banking & e-Payment
- e-Healthcare
- Transportation
- Network Security
- Access Control
- Automatic Fare Collection
- Public Transportation Terminal
- Loyalty Program
Pictures of ACS ACR1281U-C1 Dual-Interface Smart Card Reader, IC Card Reader:
