Fully automatic cement kraft paper bag makingmachine
This machine is applied to make the printed and uncolored vest bags made of HDPE, LDPE roll film. It adopts PLC control, double step motor fixed length and the liquid crystal screen actual display to finish the feeding, sealing, cutting, punching holes and transporting only in one process. It is of high degree of automation and good economic result.It's traced by 2 photocells to make the printing very exactly.
Feature:
1.The whole machine adopts microcomputer control and material-pulling by stepping motor(Servomotor control system can also be selected and equipped).
2.Arbitrary fixed-length,accurate and stable step photoelectric tracking stopping automatically when the label is lost,photoelectriccontrol feeding
3.Automatic counting and set able counting alarm.
4.Automatic constant temperature makes the sealing of bag opening firm and smooth.
5.Non-printing material can make bags in duoble lines by 4rolls feeding,making 4bas in one time.
Material processed:
HDPE/LDPE/LLDPE (as per the quality and usage of the film)
Main Technical Parameter:
MODEL |
SLZDT600 |
SLZDT700 |
SLZDT800 |
Bag Width (Max) |
550MM |
650MM |
750MM |
Bag Length |
100-1200MM |
100-1500MM |
100-1600MM |
Converting Thickness |
0.01-0.10mm |
0.01-0.10mm |
0.01-0.10mm |
Accuracy Length |
±1 |
±1 |
±1 |
Speed Cut/Min |
30-140 |
30-140 |
30-140 |
Motor |
1.1kw/1.5HP |
1.1kw/1.5HP |
1.1kw/1.5HP |
Heater |
2kw |
2.2kw |
2.3kw |
Power Required |
4.3KW |
4.5KW |
4.6KW |
Dimension (L×W×H) |
2800×1180×1900MM |
2800×1280×1900MM |
2900×1380×1900MM |
Gross Weight |
600kg |
700kg |
800kg |
