aac block supplier autoclave aerated concrete block aac panel
- 300000 Cubic Meter / Cubic Meters per Month
- WUHAN / SHANGHAI
- T/T Credit Card
Product Details
Place of Origin: | Hubei, China | Brand Name: | jinyi | Model Number: | JY-aac |
Panel Material: | Nonmetal | Type: | Other, AAC panel |
Product Description
AAC Panel
AAC Panel (Autoclaved Aerated Concrete Panel) is also called ALC Panel (Autoclaved Lightweight Concrete Panel), which is steel mesh reinforced, lightweight and loadbearing.
Below are our standard sizes:
Product Name | Height/Length (mm) | Width/Height (mm) | Thickness (mm) |
AAC External Panel | ≤3600 | 600 | 100 |
AAC Extenral Panel | ≤4200 | 600 | 120 |
AAC External Panel | ≤5200 | 600 | 150 |
AAC External Panel | ≤6000 | 600 | 175 |
AAC Extenral Panel | ≤6000 | 600 | 200 |
AAC Internal Panel | ≤3000 | 600 | 75 |
AAC Internal Panel | ≤4000 | 600 | 100 |
AAC Internal Panel | ≤5000 | 600 | 120 |
AAC Internal Panel | ≤6000 | 600 | 150 |
AAC Internal Panel | ≤6000 | 600 | 175 |
AAC Internal Panel | ≤6000 | 600 | 200 |
AAC Floor Slab | ≤1800 | 600 | 75 |
AAC Floor Slab | ≤2100 | 600 | 100 |
AAC Floor Slab | ≤2400 | 600 | 120 |
AAC Floor Slab | ≤3400 | 600 | 150 |
AAC Floor Slab | ≤4500 | 600 | 200 |
AAC Floor Slab | ≤5700 | 600 | 250 |
AAC Floor Slab | ≤6000 | 600 | 300 |
AAC Roof Slab | ≤2700 | 600 | 100 |
AAC Roof Slab | ≤3500 | 600 | 120 |
AAC Roof Slab | ≤4000 | 600 | 150 |
AAC Roof Slab | ≤6000 | 600 | 200 |
AAC Roof Slab | ≤6000 | 600 | 250 |
AAC Roof Slab | ≤6000 | 600 | 300 |
AAC Special Panel 1 | ≤2400 | 600 | 50 |
AAC Special Panel 2 | ≤3000 | 600 | 75 |
Features & Advantages of precast concrete lightweight aac panel
1. Lightweight: Aerated concrete density is usually 400-900 kg/m3(according to the market),
which is 1/3 of clay block and 1/5 of common concrete.
2.Fireproof: Most of the major raw materials is inorganic materials, so it has good fire resistance,
and do not emit harmful gases when meet fire
3.Sound insulation: As the material inside has a large numbers of the pores and porous, which
has a good thermal insulation properties.
4.Thermal Insulation: Thermal conductivity is 0.9-0.22 W/(MK), which is 1/4 of clay bricks.
5.Anti-seismic: It can improve the two seismic than the brick level.
new building material aac panel making procedure:
Advantage:
1. Lightweight:
Porosity achieve 70% to 85%, volume density is generally 500 ~ 900kg/m3, as 1/5 of general concrete the 1/4of clay, the 1/3 of hollow brick, and similar with wood can float in water. It can reduce building weight, reduction in the cost of integrated building.
2. Fireproof:
Most of the major raw materials is inorganic materials, so it has good fire resistance, and do not emit harmful gases when meet fire. Fire 650 degrees, as a refractory material, the thick up of 90mm walls can reach to 245 minutes fire resistance, 300mm thick up wall can reach to 520 minutes fire resistance.
3. Sound insulation:
Due to a unique porous structure, so it has a sound absorption capacity. The sound absorption capacity can reach of 10mm thick wall up to 41 db.
4. Heatproof:
As the material inside has a large numbers of the pores and porous, which has a good thermal insulation properties. The Thermal conductivity is 0.11-0.16W/MK, as 1/4-1/5 of brick. Typically, the insulation effect of 20cm thick aerated concrete wall is equivalent to 49cm thick solid brick walls ordinary.
5. Permeability:
Result of material by the composition of many independent small pores, the moisture absorption is slow, in the volume of absorbent is 5 times of clay saturation do. When used in the bathroom, the wall can be treated to interface directly paste tiles.
6. Anti-seismic:
The same building structure, improve the two seismic than the brick level.
7. Green:
Manufacturing, transportation, all use the process of pollution, to protect arable land, saving energy, is one kind of a green building material.
8. Durability:
material strength is stability, in the specimens tested after one year of atmospheric exposure; the intensity increased by 25%, and remained stable after ten years.
9. Shortcut:
it has good machinability, can be sawed, planed, drilled, nailed, and available appropriate as bonding of adhesive material, so create favorable conditions for building construction.
10. Economies:
An integrated lower cost than using more than 5% of solid clay bricks, and can increase the usable area, greatly enhance the utilization of floor space.
FAQ
1. What products can supply?
Answers: External Panel, Internal Panel, Floor, Roof, Fence, Wall Cladding, Wall Blocks etc.
2. What are The Features of Hubei jinyi AAC Panel?
Answers: Lightweight, Good Strength, Sound Insulation, Heat Insulation, Fireproofing, Ant-vibration, Load-bearing, No Radioactivity, fast installation
3. Why choose Hubei Jinyi AAC Panel?
Answers: Hubei jinyi provide with first-class quality in the world & Chinese Prices; always satisfied service for customers
4. Terms of payment?
Answers: T/T or L/C
5. Lead time of Hubei Jinyi ?
Answers: from 7 days to 20 days as per different order
