AAC Panel
AAC Panel (Autoclaved Aerated Concrete Panel) is also called ALC Panel (Autoclaved Lightweight Concrete Panel), which is steel mesh reinforced, lightweight and loadbearing.
Below are our standard sizes:
Product Name |
Height/Length (mm) |
Width/Height (mm) |
Thickness (mm) |
| AAC External Panel | ≤3600 | 600 | 100 |
| AAC Extenral Panel | ≤4200 | 600 | 120 |
| AAC External Panel | ≤5200 | 600 | 150 |
| AAC External Panel | ≤6000 | 600 | 175 |
| AAC Extenral Panel | ≤6000 | 600 | 200 |
AAC Internal Panel |
≤3000 |
600 |
75 |
| AAC Internal Panel | ≤4000 | 600 | 100 |
| AAC Internal Panel | ≤5000 | 600 | 120 |
| AAC Internal Panel | ≤6000 | 600 | 150 |
| AAC Internal Panel | ≤6000 | 600 | 175 |
| AAC Internal Panel | ≤6000 | 600 | 200 |
| AAC Floor Slab | ≤1800 |
600 | 75 |
| AAC Floor Slab | ≤2100 | 600 | 100 |
| AAC Floor Slab | ≤2400 | 600 | 120 |
| AAC Floor Slab | ≤3400 | 600 | 150 |
| AAC Floor Slab | ≤4500 | 600 | 200 |
| AAC Floor Slab | ≤5700 | 600 | 250 |
| AAC Floor Slab | ≤6000 | 600 | 300 |
| AAC Roof Slab | ≤2700 | 600 | 100 |
| AAC Roof Slab | ≤3500 | 600 | 120 |
| AAC Roof Slab | ≤4000 | 600 | 150 |
| AAC Roof Slab | ≤6000 | 600 | 200 |
| AAC Roof Slab | ≤6000 | 600 | 250 |
| AAC Roof Slab | ≤6000 | 600 | 300 |
| AAC Special Panel 1 | ≤2400 | 600 | 50 |
| AAC Special Panel 2 | ≤3000 | 600 |
75 |
Features & Advantages of precast concrete lightweight aac panel
1. Lightweight: Aerated concrete density is usually 400-900 kg/m3(according to the market),
which is 1/3 of clay block and 1/5 of common concrete.
2.Fireproof: Most of the major raw materials is inorganic materials, so it has good fire resistance,
and do not emit harmful gases when meet fire
3.Sound insulation: As the material inside has a large numbers of the pores and porous, which
has a good thermal insulation properties.
4.Thermal Insulation: Thermal conductivity is 0.9-0.22 W/(MK), which is 1/4 of clay bricks.
5.Anti-seismic: It can improve the two seismic than the brick level.
new building material aac panel making procedure:
Advantage:
1. Lightweight:
Porosity achieve 70% to 85%, volume density is generally 500 ~ 900kg/m3, as 1/5 of general concrete the 1/4of clay, the 1/3 of hollow brick, and similar with wood can float in water. It can reduce building weight, reduction in the cost of integrated building.
2. Fireproof:
Most of the major raw materials is inorganic materials, so it has good fire resistance, and do not emit harmful gases when meet fire. Fire 650 degrees, as a refractory material, the thick up of 90mm walls can reach to 245 minutes fire resistance, 300mm thick up wall can reach to 520 minutes fire resistance.
3. Sound insulation:
Due to a unique porous structure, so it has a sound absorption capacity. The sound absorption capacity can reach of 10mm thick wall up to 41 db.
4. Heatproof:
As the material inside has a large numbers of the pores and porous, which has a good thermal insulation properties. The Thermal conductivity is 0.11-0.16W/MK, as 1/4-1/5 of brick. Typically, the insulation effect of 20cm thick aerated concrete wall is equivalent to 49cm thick solid brick walls ordinary.
5. Permeability:
Result of material by the composition of many independent small pores, the moisture absorption is slow, in the volume of absorbent is 5 times of clay saturation do. When used in the bathroom, the wall can be treated to interface directly paste tiles.
6. Anti-seismic:
The same building structure, improve the two seismic than the brick level.
7. Green:
Manufacturing, transportation, all use the process of pollution, to protect arable land, saving energy, is one kind of a green building material.
8. Durability:
material strength is stability, in the specimens tested after one year of atmospheric exposure; the intensity increased by 25%, and remained stable after ten years.
9. Shortcut:
it has good machinability, can be sawed, planed, drilled, nailed, and available appropriate as bonding of adhesive material, so create favorable conditions for building construction.
10. Economies:
An integrated lower cost than using more than 5% of solid clay bricks, and can increase the usable area, greatly enhance the utilization of floor space.
FAQ
1. What products can supply?
Answers: External Panel, Internal Panel, Floor, Roof, Fence, Wall Cladding, Wall Blocks etc.
2. What are The Features of Hubei jinyi AAC Panel?
Answers: Lightweight, Good Strength, Sound Insulation, Heat Insulation, Fireproofing, Ant-vibration, Load-bearing, No Radioactivity, fast installation
3. Why choose Hubei Jinyi AAC Panel?
Answers: Hubei jinyi provide with first-class quality in the world & Chinese Prices; always satisfied service for customers
4. Terms of payment?
Answers: T/T or L/C
5. Lead time of Hubei Jinyi ?
Answers: from 7 days to 20 days as per different order
