DHP-25P/350P Pre-filled Syringe Blister Packing Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2010
Factory Size:
3,000-5,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
DPP-250EI Blister Packing Machine(ALU ALU ALU PVC)NegotiableMOQ: 1 -
GH Series Full Servo Blister Packing MachineNegotiableMOQ: 1
-
ZHW-600L Vials Cartoning MachineNegotiableMOQ: 1
-
ZHB-100 AUTOMATIC CARTONING MACHINE (for Bottle)NegotiableMOQ: 1
-
ZHW-120 AUTOMATIC CARTONING MACHINE (for Ice-cream)NegotiableMOQ: 1
Applications:
The machine suitable for ampoule, vials and pre-filled syringe etc .blister packing , adopts automatic feeding system. Machine feeder can be connect with labeling machine ,and output can use with cartoning machine,
thus formed a complete automatic packaging production line.
Feature:
1.Machine with GMP standard,adopts PLC control system.
2.Uses the servo motor -driven and the main motor is adopts frequency control
3.Specially automatic servo drive feeder for ampoule,vial,pre-filled
4.Equipped blister forming detection ,feeding detect rejection
5.Uses the safety cover protection devices to ensure operator safety.
| Maximum blanking frequency | 25times/minute |
| Maximum Working capacity |
DHP-250P:100 blisters/min
DHP-350P:150 blisters/min
|
| Stroke | ≤130mm(according to customer's request) |
| Maximum forming area |
DHP-250P:245×130x35mm
DHP-350P:345x130x35mm
|
| Packaging materials |
DHP-250P: PVC:260×0.25(0.15-0.5)mm
PTP:260×0.02mm
DHP-350P: PVC:350×0.25(0.15-0.5)mm
PTP:3500×0.02mm
|
| Power supply | 380V or 220V |
| Total power |
DHP-250P: 6Kw
DHP-350P: 7Kw
|
| Air flow | ≥0.38m3/min |
| Dimension of machine(L×W×H) | 4500×850×1700mm |
| Weight |
DHP-250P: 2500kg
DHP-350P: 3000kg
|
