Home > Manufacturing & Processing Machinery > Woodworking Machinery > Wood Pellet Mill > 9FQ-40 Hammer Mill for Wood Chips

9FQ-40 Hammer Mill for Wood Chips

9FQ-40 Hammer Mill for Wood Chips thumbnail-1
9FQ-40 Hammer Mill for Wood Chips photo-1
US$ 200 - 6,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Henan, China
Brand Name:
HYPH
Contact Supplier Request Quote Chat Now
Henan Double Elephants Machinery I/E Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Henan, China
Brand Name HYPH
Model Number 9FQ-40
Voltage 380V
Power(W) 7.5kW
Weight 200KG
Certification ISO,CE,SGS
Warranty one year, 1year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.Fine grinding;
2.Simple operation;
3.Low consumption;
4.Corn wood hammer mill;
5.High productivity and efficiency;

Introduction

It is one kind of small crush machine, the knife can cut and crush the raw material with 1mm diameter.As for the wood

chips, stick, straw and stalk into pieces can be as required



It is suitable for grinding the grains, such corn, wheat, straw, etc. If for wood and paring, use different hammer.



This kind of machine could be matched with mounting plate for motor or diesel engine, tractor and collector.







Features



 1 Even crushing function of multi-cavities which is suitable to crush hard material.




 2 Reasonable design of leveling plate making the finished material finer and cubic-shaped without internal cracks.




 3 Low and big feed opening make the production line easy to arrange and increase the size of feeding material.




 4 Hydraulic start-up which is convenient for maintenance and replacement of wear-parts.


 5 New anti-abrasive material which prolong service life of impact hammer, impact plate and liner.







Main Data

No.

Model

Power

 (kw)

Weight of mill

 (kg)

Capacity

 (kg/h)

1

9FQ-20

1.1Kw/380v/50Hz

       50

  100-200

2

9FQ-20W

       60

3

9FQ-26

1.5kw/380v/50Hz

       60

  200-300

4

9FQ-26W

       70

5

9FQ-30

3kw/380v/50Hz

       80

  250-350

6

9FQ-30C

       100

7

9FQ-32

5.5kw/380v/50Hz

       120

  300-350

8

9FQ-32C

       135

9

9FQ-36

5.5kw/380v/50Hz

       160

  400-500

10

9FQ-36C

       180

11

9FQ-40

7.5kw/380v/50Hz

       180

  500-800

12

9FQ-40C

       200

13

9FQ-50

11Kw/380v/50Hz

       200

  800-1200

14

9FQ-50C

       230
