semi auto blow molding machine
Features:
l Adopt the new type double bend arm and four pull rod-clamping structure (won the patent). Cross direction; middle mould board is move parallel; the distance between two mold bases is adjusted by the chain wheel. Thus, the clamping force is very strong.
l The machine frame is produced by the whole complete casting bottom, so that the machine is firm and running stable.
l Adopt the straight slide way, reduce the friction and lengthen the life of the machine.
l Double start working button, which is designed for avoiding the injury.
l Power saving design that can increase your profits.
l The single direction of pre-form placing and bottle picking, which increase the output.
l Segregate type air controlling system, which is designed for avoiding waste pollution.
l The stretching air cylinder is adjusted parallel from front to back, from left to right freely by regulator.
Technical Parameter:
GENERAL INFO |
YD-1500 |
Theoretial output |
700~1500PCS/hr |
Heating capacity |
9.8kw |
Max bottle volume |
1.5L(2 cav) |
Blowing pressure |
≤3.5Mpa |
Motion Pressure |
≤1.0Mpa |
Max*deameter*height |
Ø 140XH340mm |
Mould thickness |
120~220mm |
Weight |
850kg |
Main Machine |
1450*700*1750mm |
Heater |
1800*750*1400mm |
About Factory
15years’ experience in filling line machinery; 12 years gold supplier on .
About Quality
Brand-new equipments with latest design and suitable material made,
About After Sale Service
one year's warranty period and life time technical support.
