Q35y-16 hydraulic iron workers iron worker ironworker machine punch and shears steel punching and shear machine
hydraulic Combined round square bar pipes tubes angle H beam steel punching and shearing cutting ironworker iron workers machine
They adopt hydraulic driving system and they are the latest iron workers in our country,Various metal plate,squarebar,Round bar,angle,channel and joist can be cut,punched and notched on the machine.It is also equipped with a stop device for cutting.
Multiple functions including: Punch, Angle Shear, Flat Shear, Round, Square Bar Shear, Rec. Notch, V-Notch, Channel Shear,I beam shear,shearing T-bar, Press Brake, Angle Bending and Pipe Notching! It comes standard with: quick-change coupling nut & sleeve, squaring arm with scale, electronic back gauge, gauging table with stops, punching base table, safety guards and more.
PUNCHING- The Punching Station offers a full range of universal punches and dies. Unique style allows for large angle iron punching and large channel punching. A large stripper viewing window and the swing away design offers ease of operation. Two-piece gauging table with rulers and stop is offered as standard equipment. Quick change coupling nut and sleeve makes for rapid replacement or changing of the die in use.
FLAT SHEARING- At the Flat Bar Shearing Station you can easily adjust the hold for precision cutting and shearing without loosing operator visibility. The large 15-inch squaring arm is inlaid with a scale and comes standard on all machines. A specially contoured anti-distortion blade provides quality cuts while a lower blade offers maximum versatility with four usable edges. Set Screws allow for easy gapping with no shimming required. An included large squaring arm makes miter cuts easy to do. Three-foot electronic back gauge allows for fine adjustment and precision accuracy and features a large contact button for maximum productivity. The fully protected electrical harness offers both safety and reliability.
ANGLE SHEARING- The angle cut shear has the ability to cut angled iron at a 45°and 90° angle from both the top and bottom leg, allowing for a picture frame like corner to be made for perfect welds. Installed safety guards are both large and strong offering protection while the machine is in use.
BAR SHEARING- Round and Square bar shearing station has multiple holes for a variety of sizes. The adjustable hold-down provides a clean squaring cut and with large, heavy-duty knobs the precise hold can be made.
Model |
Q35Y-16 |
Q35Y-20 |
Q35Y-25 |
Q35Y-30 |
Q35Y-40 |
Q35Y-50 |
||
Processing Capacity (KN) |
600 |
900 |
1200 |
1600 |
2000 |
2500 |
||
Material Tensile Strength (Mpa) |
≤450 |
≤450 |
≤450 |
≤450 |
≤450 |
≤450 |
||
Flat Shearing |
Max. Shearing Capacity (thickness* width (mm) |
16×250 |
20×330 |
25×330 |
30×355 |
35×400 |
40×450 |
|
8×400 |
10×480 |
16×600 |
20×600 |
25×700 |
30×750 |
|||
Bar Shearing |
Square Bar(mm) |
40 |
45 |
50 |
55 |
60 |
65 |
|
Round Bar (mm) |
45 |
50 |
60 |
65 |
70 |
80 |
||
C-channel (mm) |
126 |
160 |
200 |
280 |
300 |
320 |
||
I-beam (mm) |
126 |
160 |
200 |
280 |
300 |
320 |
||
Angle shearing |
90° shearing (mm) |
120×12 |
140×12 |
160×14 |
180×16 |
200X18 |
200×20 |
|
45° shearing (mm) |
70x8 |
70x10 |
80x7 |
80x10 |
80x10 |
80x10 |
||
Hole Punching |
Max. Punching Capacity (diameter* thickness) (mm) |
Φ25*16 |
Φ30*20 |
Φ35*25 |
Φ38*26 |
Φ40*35 |
Φ40*40 |
|
Motor (KW) |
4 |
5.5 |
7.5 |
11 |
15 |
18.5 |
||
Dimension(mm) |
Length |
1650 |
1950 |
2350 |
2680 |
2800 |
3200 |
|
Width |
800 |
900 |
980 |
1060 |
1260 |
1440 |
||
Height |
1780 |
1930 |
2100 |
2380 |
2420 |
2450 |
||
Weight |
1800 |
2600 |
4400 |
6600 |
7500 |
0800 |
||
|
|
|
|
