Home > Manufacturing & Processing Machinery > Machine Tools > Punching Machine > Chinese Supplier Horizontal Profile Bending Machine With Low Price

Chinese Supplier Horizontal Profile Bending Machine With Low Price

Name: Chinese Supplier Horizontal Profile Bending Machine With Low Price
Brand: JUGAO
SKU: 107517487

US$ 3,000 - 4,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

CNC or Not:

Normal

Power Source:

Hydraulic

Contact Supplier Request Quote Chat Now

Nantong Jugao Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

ShangHai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

CNC or Not Normal

Power Source Hydraulic

Place of Origin Jiangsu, China

Brand Name JUGAO

Model Number WC67K

Voltage 220V/380V/415V

Power(W) 7.5KW

Weight 1700--6200KG

Dimension(L*W*H) 160CMX80CMX160CM

Certification CE

Warranty 100% one year

After-sales Service Provided Engineers available to service machinery overseas

We can talk on line now. Please click me.

Product Description

Q35y-16 hydraulic iron workers iron worker ironworker machine punch and shears steel punching and shear machine

hydraulic Combined round square bar pipes tubes angle H beam steel punching and shearing cutting ironworker iron workers machine

They adopt hydraulic driving system and they are the latest iron workers in our country,Various metal plate,squarebar,Round bar,angle,channel and joist can be cut,punched and notched on the machine.It is also equipped with a stop device for cutting.

Multiple functions including: Punch, Angle Shear, Flat Shear, Round, Square Bar Shear, Rec. Notch, V-Notch, Channel Shear,I beam shear,shearing T-bar, Press Brake, Angle Bending and Pipe Notching! It comes standard with: quick-change coupling nut & sleeve, squaring arm with scale, electronic back gauge, gauging table with stops, punching base table, safety guards and more.

PUNCHING- The Punching Station offers a full range of universal punches and dies. Unique style allows for large angle iron punching and large channel punching. A large stripper viewing window and the swing away design offers ease of operation. Two-piece gauging table with rulers and stop is offered as standard equipment. Quick change coupling nut and sleeve makes for rapid replacement or changing of the die in use.

FLAT SHEARING- At the Flat Bar Shearing Station you can easily adjust the hold for precision cutting and shearing without loosing operator visibility. The large 15-inch squaring arm is inlaid with a scale and comes standard on all machines. A specially contoured anti-distortion blade provides quality cuts while a lower blade offers maximum versatility with four usable edges. Set Screws allow for easy gapping with no shimming required. An included large squaring arm makes miter cuts easy to do. Three-foot electronic back gauge allows for fine adjustment and precision accuracy and features a large contact button for maximum productivity. The fully protected electrical harness offers both safety and reliability.

ANGLE SHEARING- The angle cut shear has the ability to cut angled iron at a 45°and 90° angle from both the top and bottom leg, allowing for a picture frame like corner to be made for perfect welds. Installed safety guards are both large and strong offering protection while the machine is in use.

BAR SHEARING- Round and Square bar shearing station has multiple holes for a variety of sizes. The adjustable hold-down provides a clean squaring cut and with large, heavy-duty knobs the precise hold can be made.

Model			Q35Y-16	Q35Y-20	Q35Y-25	Q35Y-30	Q35Y-40	Q35Y-50
Processing Capacity (KN)			600	900	1200	1600	2000	2500
Material Tensile Strength (Mpa)			≤450	≤450	≤450	≤450	≤450	≤450
Flat Shearing	Max. Shearing Capacity (thickness* width (mm)		16×250	20×330	25×330	30×355	35×400	40×450
Flat Shearing	Max. Shearing Capacity (thickness* width (mm)		8×400	10×480	16×600	20×600	25×700	30×750
Bar Shearing	Square Bar(mm)		40	45	50	55	60	65
	Round Bar (mm)		45	50	60	65	70	80
	C-channel (mm)		126	160	200	280	300	320
	I-beam (mm)		126	160	200	280	300	320
Angle shearing	90° shearing (mm)		120×12	140×12	160×14	180×16	200X18	200×20
Angle shearing	45° shearing (mm)		70x8	70x10	80x7	80x10	80x10	80x10
Hole Punching	Max. Punching Capacity (diameter* thickness) (mm)		Φ25*16	Φ30*20	Φ35*25	Φ38*26	Φ40*35	Φ40*40
Motor (KW)			4	5.5	7.5	11	15	18.5
Dimension(mm)		Length	1650	1950	2350	2680	2800	3200
		Width	800	900	980	1060	1260	1440
		Height	1780	1930	2100	2380	2420	2450
Weight			1800	2600	4400	6600	7500	10800
