Cnc Steel Sheet Bend Machinery
US$ 5000.00 - 5000.00
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
JUGAO
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
WC67K-63T/25000mm ,aluminum Sheet Bending Machine, 2.5M Metal Plate Press Brake Quality ChoiceUS$ 6,000 - 7,000MOQ: 1 Acre -
Plate Bending Machinery for Steel Stainless Plate RollingUS$ 6600.00 - 6600.00MOQ: 1 Set
-
Cnc Controlled Backgauge Press Brake 3D Visualisation Bending Machine With USB ConnectionUS$ 4,000 - 6,000MOQ: 1 Acre
-
Asymmetric 3 Roller Bending MachineUS$ 5000.00 - 5000.00MOQ: 1 Set
-
World Top Brand Nanjing QC12Y Cnc Metal Sheet Shear Equipment With Highest QualityUS$ 4,000 - 6,000MOQ: 1 Set
Condition
New
Place of Origin
Jiangsu, China
Brand Name
JUGAO
Model Number
W11SNC
Machine Type
Roller-Bending Machine
Raw Material
Sheet / Plate Rolling
Material / Metal Processed
Carbon Steel
Power
Hydraulic
Automation
Automatic
Extra Services
End Forming
Certification
ISO 9001:2000
After-sales Service Provided
Engineers available to service machinery overseas
We can talk on line now. Please click me.
Company Information
| 1.Company Name: Nantong Jugao Machinery Co Ltd |
| 2.Machine Brand: JUGAO |
| 3.JUGAO is leading manufacturer: bending machine, press brake, shearing machine, punching machine, power press, Ironworkers, rolling machine and hydraulic press etc. |
|
4.Official website: Email: info(at) Tel;008613222111178 |
| 5.JUGAO machine video:/user/gaohua616 |
Product Description
cnc plate rolling machine roll bending machine bending roll machine sheet rolling machine cnc plate bending machinery
cnc sheet bend machinery bending roller machine steel plate rolling machine steel sheet bending roller machine
|
This model device adopts the Japanese technology. It can roll plate to cylinder, cone, U-shape and so on. The up roller of this device can do up and down, right and left move. And all the move actions can show by figure.It with the pre-bending capacity. |
| steel plate rolling machine vertical displacement of upper roller has a digital display, eye-catching and intuitive. This products Shang roll universal type volume Board Shang roll can upper and lower mobile, also can level mobile, Shang roll upper and lower mobile used to change plate bent curvature, before and after mobile used to change Shang roll axis line vertical face said location, achieved plate of end Department pre bent and meet various bent by needed of process requirements, so no plus pressure machine, additional equipment, can once Shang material, not needed turn on can completed plate ends Department of pre bent and the forming bent function, and for forming artifacts of correction. |
| high accurate end pre-bending: free set of straight edge length, roll pressure directly on pre-bent, able to complete accurate end pre-bending. |
| superior product precision: roll on a drum-shaped, roll down the lower idler tie in regulation, consecutive bends, from thin to thick plates ideal voucher system within this broad range of products. |
steel plate rolling machine description:
| steel plate rolling machine on this device for roller omnipotent steel plate rolling machine used for bending a certain thickness of the metal sheet at room temperature into a tube-shaped, curved or there is a taper of parts. The works by Rotary bending deformation. Upper roller can be moved up and down, and also move horizontally, so it does not need additional press and additional equipment to feed at a time, without having to turn to complete end pre-bending and bending of the plate features, as well as for correction of the workpiece. Using assistive devices can make the ends of sheets, and fewer remaining straight edge. Is oil, chemical, cement, shipbuilding, boilers, air, water, power transmission towers and other necessary equipment for the machinery and equipment manufacturing industry. |
| The structure of this machine has four rollers, the upper roller is main drive, through the hydraulic motor provides the power to provide torque for coiled sheet; lower roller for vertical movement by hydraulic cylinder, to the clamping was coiled sheet, and the realization of non symmetric bending roll system. |
| This machine is three rollers symmetries rolling mild steel or mild alloy steel under normal temperature condition (such as Q235, Q345, 16MnR, etc.) into cylinders. |
| The machine is suitable for sheet metal bending, can be rolled round and arc and within a certain range of conical workpiece, and sheet metal bending function, the remaining straight edge, high work efficiency, and can be used crude the metal plate to be leveling. |
The upper roller is arranged the side roller device, the side roller is parallel to the roller axis for arc lifting motion, the side roller arc movement by the hydraulic cylinder. |
Hydraulic element selects the import high quality products, guarantee the stability of the hydraulic system.
| All hydraulic system input, outlet are set with corresponding control point, easy for maintenance and fault inspection. Oil pump adopt underneath type, positive pressure oil absorption. At the same time the filter and liquid ometer are equipped with hair-device, it can automatic alarm the disturbance display. The hydraulic station is set independent outside of machine, easy for maintenance, also it’s away from the heat source. |
| Production system strictly obey the international, line standard. The radius of bent tube is reasonable, and not less than 90 °, smooth transition, effectively avoid the impact and vibration |
| System design full consideration of high efficiency and energy saving, reducing power waste, reduce heat source. |
| Equipped with high precision oil absorption and oil return filter, in order to ensure the cleanliness of the oil system. |
| Provide rolling machine hydraulic system common fault phenomenon and elimination method. |
| In order to ensure the manufacturing quality of hydraulic system, the system produce according to the hydraulic professional manufacturers and National GB3766-83 "hydraulic system general technical conditions” |
| The tank is cleaned by the shot blasting, pickling and surface cleaning, the walls is coated oil varnish to make sure the cleaning of tank. There is the air filter in the fuel oil tank place to make sure the function of the oil filter and ventilation. There is equipped with the fine filter on the oil suction pipe end and way for tubing. |
| Hydraulic system normal operating temperature range is 15 °C ~ 65 °C. It can be automatic heating through the electric heater when the temperature is less than 15 °C. It can control, the oil temperature through the cooler when the temperature is more than 65 °C. It’s suitable for the requirements of the system. |
| Model | Pressure (Ton) |
Max bending thickness (mm) |
Max rolling length mm |
Upper roller diameter mm |
Down roller diameter mm |
Rollers distance |
Motor kw | |||
|
Pre-bending mm |
Max bending mm |
mm | Driving | Hydraulic | Moving | |||||
| 6x1500 | 25 | 4.8 | 6 | 1500 | 175 | 125 | 160 | 3 | 2.2 | 0.75 |
| 6x2000 | 25 | 4.8 | 6 | 2000 | 195 | 125 | 160 | 3 | 2.2 | 0.75 |
| 6x2500 | 25 | 4.8 | 6 | 2500 | 205 | 135 | 180 | 3 | 2.2 | 0.75 |
| 6x3000 | 37 | 4.8 | 6 | 3000 | 215 | 135 | 180 | 4 | 2.2 | 0.75 |
| 8x1500 | 25 | 6.4 | 8 | 1500 | 175 | 125 | 160 | 3 | 2.2 | 0.75 |
| 8x2000 | 25 | 6.4 | 8 | 2000 | 195 | 125 | 160 | 3 | 2.2 | 0.75 |
| 8x2500 | 37 | 6.4 | 8 | 2500 | 205 | 135 | 180 | 4 | 2.2 | 0.75 |
| 8x3000 | 45 | 6.4 | 8 | 3000 | 215 | 135 | 180 | 4 | 2.2 | 0.75 |
| 10x1500 | 37 | 8 | 10 | 1500 | 205 | 135 | 180 | 4 | 2.2 | 0.75 |
| 10x2000 | 45 | 8 | 10 | 2000 | 215 | 135 | 180 | 4 | 2.2 | 0.75 |
| 10x2500 | 45 | 8 | 10 | 2500 | 235 | 135 | 180 | 4 | 2.2 | 0.75 |
| 10x3000 | 65 | 8 | 10 | 3000 | 245 | 135 | 180 | 5.5 | 4 | 0.75 |
| 10x4000 | 75 | 8 | 10 | 4000 | 255 | 150 | 245 | 7.5 | 4 | 1.1 |
| 12x2000 | 65 | 9.6 | 12 | 2000 | 250 | 145 | 200 | 5.5 | 4 | 0.75 |
| 12x2500 | 65 | 9.6 | 12 | 2500 | 255 | 150 | 245 | 5.5 | 4 | 0.75 |
| 12x3000 | 75 | 9.6 | 12 | 3000 | 270 | 150 | 245 | 7.5 | 4 | 1.1 |
| 12x6000 | 100 | 9.6 | 12 | 6000 | 290 | 150 | 245 | 15 | 5.5 | 1.5 |
| 16x2000 | 75 | 12.8 | 16 | 2000 | 255 | 150 | 245 | 7.5 | 4 | 1.1 |
| 16x2500 | 100 | 12.8 | 16 | 2500 | 270 | 150 | 245 | 15 | 5.5 | 1.5 |
| 16x3200 | 100 | 12.8 | 16 | 3200 | 290 | 150 | 245 | 15 | 5.5 | 1.5 |
| 16x6000 | 190 | 12.8 | 16 | 6000 | 300 | 165 | 270 | 22 | 7.5 | 4 |
| 20x2000 | 100 | 16 | 20 | 2000 | 325 | 165 | 270 | 15 | 5.5 | 1.5 |
| 20x2500 | 130 | 16 | 20 | 2500 | 330 | 180 | 300 | 15 | 5.5 | 1.5 |
| 20x3000 | 160 | 16 | 20 | 3000 | 350 | 180 | 300 | 18.5 | 7.5 | 2.2 |
| 20x4000 | 190 | 16 | 20 | 4000 | 360 | 200 | 330 | 22 | 7.5 | 4 |
| 20x6000 | 380 | 16 | 20 | 6000 | 375 | 200 | 330 | 45 | 22 | 5.5 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Packaging & Shipping
Our Services
1.Standardization of Service “212" |
| 2: response in 2 hours |
| 1: provide solution in 1 day |
| 2: solve complaint in 2 days |
| 2.Installation Service |
| Installation Services are available with all Accurl machines. We dispatch technician to customer's factory for installation and preoperation of machines. ( Customers only need to pay the airfare and hotel ) |
| 3.Training Service |
| Our technician is available to your factory and offer training of how to use our machines. As well, you may send your technician to our company to learn how to operate machines. |
| 4.Quality Guarantee |
| We guarantee the quality of machine (e.g. processing speed and working performance is the same as the data of samples making). We sign the agreement with detailed technical data. |
| We arrange final test before shipment. We run the machine for a few days, and then use customer's materials for test. After making sure machine is the best performance, then make shipments. |
| Machine warranty is 3 year. We offer flexible extended warranties if needed. |
FAQ
1. How about your machine quality?We are worry about the quality.
|
RE:JUGAO is a mature brand in CHINA,through our 20 years research in technology,our design including structure and detailed sercurity and precision has enhanced greatly,and can match all the CE standard or more strict standard.Our machines distribute worldwide to about 50countries where there are metal plate industry ,there are Brillante machines.And where there are our machines,there are good reputation and terminal user satisfaction. |
2. Whether the machine price can be more discount
|
RE:1.JUGAO always provide high quality machine,oversea market is more important and difficult than domestic market because of communicationtime costing after sales,So always,our machine has enough qaulity standard to make surethe machine can work more than the real warranty period.In this way ,we will save a lot and think in advance for the clients. |
