| 1.Company Name: Nantong Jugao Machinery Co Ltd |
| 2.Machine Brand: JUGAO |
| 3.JUGAO is leading manufacturer: bending machine, press brake, shearing machine, punching machine, power press, Ironworkers, rolling machine and hydraulic press etc. |
|
4.Official Website: Email: info(at) Tel:008613222111178 |
| 5.JUGAO machine video:/user/gaohua616 |
Q35y-16 hydraulic iron workers iron worker ironworker machine punch and shears steel punching and shear machine
| hydraulic Combined round square bar pipes tubes angle H beam steel punching and shearing cutting ironworker iron workers machine |
| They adopt hydraulic driving system and they are the latest iron workers in our country,Various metal plate,squarebar,Round bar,angle,channel and joist can be cut,punched and notched on the machine.It is also equipped with a stop device for cutting. |
| Multiple functions including: Punch, Angle Shear, Flat Shear, Round, Square Bar Shear, Rec. Notch, V-Notch, Channel Shear,I beam shear,shearing T-bar, Press Brake, Angle Bending and Pipe Notching! |
| It comes standard with: quick-change coupling nut & sleeve, squaring arm with scale, electronic back gauge, gauging table with stops, punching base table, safety guards and more. |
| PUNCHING- The Punching Station offers a full range of universal punches and dies. Unique style allows for large angle iron punching and large channel punching. |
| A large stripper viewing window and the swing away design offers ease of operation. Two-piece gauging table with rulers and stop is offered as standard equipment. |
Compared with other machines. Advantages of JUGAO machine.
| Quick change coupling nut and sleeve makes for rapid replacement or changing of the die in use. |
| FLAT SHEARING- At the Flat Bar Shearing Station you can easily adjust the hold for precision cutting and shearing without loosing operator visibility. |
| The large 15-inch squaring arm is inlaid with a scale and comes standard on all machines. A specially contoured anti-distortion blade provides quality cuts while a lower blade offers maximum versatility with four usable edges. |
| Set Screws allow for easy gapping with no shimming required. An included large squaring arm makes miter cuts easy to do. Three-foot electronic back gauge allows for fine adjustment and precision accuracy and features a large contact button for maximum productivity. |
| The fully protected electrical harness offers both safety and reliability. |
| ANGLE SHEARING- The angle cut shear has the ability to cut angled iron at a 45°and 90° angle from both the top and bottom leg, allowing for a picture frame like corner to be made for perfect welds. I |
Advanced technology in JUGAO MACHINES
| nstalled safety guards are both large and strong offering protection while the machine is in use. |
| BAR SHEARING- Round and Square bar shearing station has multiple holes for a variety of sizes. The adjustable hold-down provides a clean squaring cut and with large, heavy-duty knobs the precise hold can be made. |
Model |
Q35Y-16 |
Q35Y-20 |
Q35Y-25 |
Q35Y-30 |
Q35Y-40 |
Q35Y-50 |
||
Processing Capacity (KN) |
600 |
900 |
1200 |
1600 |
2000 |
2500 |
||
Material Tensile Strength (Mpa) |
≤450 |
≤450 |
≤450 |
≤450 |
≤450 |
≤450 |
||
Flat Shearing |
Max. Shearing Capacity (thickness* width (mm) |
16×250 |
20×330 |
25×330 |
30×355 |
35×400 |
40×450 |
|
8×400 |
10×480 |
16×600 |
20×600 |
25×700 |
30×750 |
|||
Bar Shearing |
Square Bar(mm) |
40 |
45 |
50 |
55 |
60 |
65 |
|
Round Bar (mm) |
45 |
50 |
60 |
65 |
70 |
80 |
||
C-channel (mm) |
126 |
160 |
200 |
280 |
300 |
320 |
||
I-beam (mm) |
126 |
160 |
200 |
280 |
300 |
320 |
||
Angle shearing |
90° shearing (mm) |
120×12 |
140×12 |
160×14 |
180×16 |
200X18 |
200×20 |
|
45° shearing (mm) |
70x8 |
70x10 |
80x7 |
80x10 |
80x10 |
80x10 |
||
Hole Punching |
Max. Punching Capacity (diameter* thickness) (mm) |
Φ25*16 |
Φ30*20 |
Φ35*25 |
Φ38*26 |
Φ40*35 |
Φ40*40 |
|
Motor (KW) |
4 |
5.5 |
7.5 |
11 |
15 |
18.5 |
||
Dimension(mm) |
Length |
1650 |
1950 |
2350 |
2680 |
2800 |
3200 |
|
Width |
800 |
900 |
980 |
1060 |
1260 |
1440 |
||
Height |
1780 |
1930 |
2100 |
2380 |
2420 |
2450 |
||
Weight |
1800 |
2600 |
4400 |
6600 |
7500 |
10800 |
||
|
|
|
|
1.Standardization of Service “212" |
| 2: response in 2 hours |
| 1: provide solution in 1 day |
| 2: solve complaint in 2 days |
| 2.Installation Service |
| Installation Services are available with all Accurl machines. We dispatch technician to customer's factory for installation and preoperation of machines. ( Customers only need to pay the airfare and hotel ) |
| 3.Training Service |
| Our technician is available to your factory and offer training of how to use our machines. As well, you may send your technician to our company to learn how to operate machines. |
| 4.Quality Guarantee |
| We guarantee the quality of machine (e.g. processing speed and working performance is the same as the data of samples making). We sign the agreement with detailed technical data. |
| We arrange final test before shipment. We run the machine for a few days, and then use customer's materials for test. After making sure machine is the best performance, then make shipments. |
| Machine warranty is 3 year. We offer flexible extended warranties if needed. |
1. How about your machine quality?We are worry about the quality.
|
RE:JUGAO is a mature brand in CHINA,through our 20 years research in technology,our design including structure and detailed sercurity and precision has enhanced greatly,and can match all the CE standard or more strict standard.Our machines distribute worldwide to about 50countries where there are metal plate industry ,there are Brillante machines.And where there are our machines,there are good reputation and terminal user satisfaction. |
2. Whether the machine price can be more discount
|
RE:1.JUGAO always provide high quality machine,oversea market is more important and difficult than domestic market because of communicationtime costing after sales,So always,our machine has enough qaulity standard to make surethe machine can work more than the real warranty period.In this way ,we will save a lot and think in advance for the clients. |
