Product image
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Product data
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
UT58 series instrument is a 3 1/2 digital manual range digital meter. With a large screen, full function symbols and the input of the prompt, full range of overload protection and unique design, so that the performance is more superior electrical instrumentation.
Can be applied to smelting, communications, manufacturing, oil, defense, power, chemical and other industries, is also the circuit / power equipment maintenance, maintenance of the ideal tool.
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Product attribute
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
| Specifications | Range | Best Accuracy |
| Model | UT58E | |
| DC Voltage (V) | 200mV/2V/20V/200V/1000V | ±(0.05%+3) |
| AC Voltage (V) | 2V/20V/200V/1000V | ±(0.5%+10) |
| DC Current (A) | 2mA/20mA/20A | ±(0.5%+5) |
| AC Current (A) | 20mA/200mA/20A | ±(0.8%+10) |
| Resistance (Ω) | 200Ω/2KΩ/20KΩ/2MΩ/200MΩ | ±(0.5%+10) |
| Capacitance (F) | 2nF/20nF/2μF/20μF | ±(3%+4) |
| Frequency (Hz) | 20KHz | ±(1.5%+5) |
| Temperature (°C) | -40 °C ~ 1000°C | ±(1%+30) |
| Features | ||
| Display Count | 2000 | |
| Manual Range | √ | |
| Diode | √ | |
| Transistor | √ | |
| Auto Power Off | √ | |
| Continuity Buzzer | √ | |
| Data Hold | √ | |
| Low Battery Indication | √ | |
| Full Icon Display | √ | |
| Input Impedance for DCV | Around 10MΩ | √ |
| Test Lead Connection Indications | √ | |
| General Characteristic | ||
| Power | 9V Battery(6F22) | |
| LCD Size | 60mm×54mm | |
| Product Color | Red and Grey | |
| Product Net Weight | 350g (Including holster) | |
| Product Size | 179mm×88mm×39mm | |
| Standard Accessories | Battery, Test Lead,Holster,Muli-Purpose Socket,Point Contact Temperature Probe | |
| Standard Individual Packing | Gift Box, English Manual | |
| Standard Quantity Per Carton | 40 PCs | |
| Standard Carton Measurement | 598mm×418mm×340mm (0.085 CBM Per Standard Carton) | |
| Standard Carton Gross Weight | 27 Kg | |
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
