Best Handheld Digital Storage Oscilloscopes UNI-T UTD1202C
US$ 701 - 736
MOQ: 2 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
UTD1202C
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Best Digital Storage Oscilloscopes UNI-T UTD2025CUS$ 160 - 168MOQ: 2 Pieces -
Best Digital Storage Oscilloscopes UNI-T UTD2062CMUS$ 731 - 767.6MOQ: 40 Pieces
-
Best Digital Storage Oscilloscopes UNI-T UTD2102CEUS$ 228.6 - 240MOQ: 2 Pieces
-
Best Digital Storage Oscilloscopes UNI-T UTD2202CEUS$ 320 - 336MOQ: 2 Pieces
-
Best Digital Storage Oscilloscopes UNI-T UTD4202C Quality ChoiceUS$ 731.4 - 768MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
UNI-T
Model Number
UTD1202C
--------------------
Product image
Product Description
1,Automatic waveform and status configuration;
2,Storage of waveforms, setups and interfaces; waveforms and setups reproduction
3,Screen copy function;
4,Fine window extension; precise analysis of waveform details and overview;
5,Unique waveform recording, storage and replay function;
6,HD color 5.7 inch LCD panel at 320 x 240 pixel aspect ratio;
7,Multiple waveform mathematics functions (including add, subtract, multiply and divide);
8,Multimeter function;
9,USB drive system software upgrade.
Product parameters
| Specification | UTD1202C | |
| Channels | 2 | |
| Bandwidth | 200MHz | |
| Sample Rate | 1GS/s | |
| Rise Time | ≤1.8ns | |
| Memory Depth | 7.5 kpts | |
| Vertical Sensitivity | 5mV-50V/div | |
| Time-based Range | 2ns/div-50s/div | |
| Storage | Setup, Waveform, Bitmap | |
| Trigger Modes | Edge, Pulse, Video and Alternative | |
| Interface | USB HOST / USB OTG (Optional) | |
| Multimeter Specifications | Range | Best Accuracy |
| DC Voltage (V) | 600mV/6V/60V/600V/1000V | ±(1%+5) |
| AC Voltage (V) (45Hz~400Hz) | 600mV/6V/60V/600V/700V | ±(1.2%+5),Frequency:<200Hz |
| ±(1.5%+5),Frequency:≥200Hz | ||
| DC Current (A) (External Convertor) | 6mA/60mA/600mA | ±(1.2%+5) |
| 6A | ±(1.5%+5) | |
|
AC Current (A) (45Hz~400Hz) (External Convertor) |
6mA/60mA/600mA | ±(2%+5) |
| 6A | ±(2.5%+5) | |
| Resistance (Ω) | 6kΩ/60kΩ/600kΩ | ±(1.2%+5) |
| 600Ω/6MΩ/60MΩ | ±(1.5%+5) | |
| Capacitance (F) | 6nF/6mF | ±(5%+10) |
| 60nF/600nF/6μF/60μF/600μF | ±(4%+5) | |
| Display Count | 6000 | |
| Auto Range | √ | |
| General Characteristic | ||
| Power |
Lithium Battery: 7.4V 4400mAh; DC Adapter: 100~240V 50/60Hz input, 9V 4A Output |
|
| Display | 5.7 Inches 64K Color TFT LCD, 320×240 | |
| Product Color | Red and Grey | |
| Product Net Weight | 1.8 Kg | |
| Product Size (W×H×D) | 268mm × 168 mm × 60mm | |
| Standard Accessories | Probe×2(1×,10× Switchable), (Current Voltage Convertor)×2, Power Cord ,DC Adaptor, Test Lead, PC Software CD | |
| Standard Individual Packing | Gift Box,Carrying Bag, English Manual | |
| Standard Quantity Per Carton | 4 PCs | |
| Standard Carton Measurement (L×W×H) | 500mm × 400mm × 320mm | |
| Standard Carton Cross Weight | 10.8 Kg | |
| Optional Accessories | ||
| USB OTG | ||
