| Specifications | Range | Best Accuracy | |
| Model | UT592 | ||
| Insulation Resistance (Ω) | Test Voltage | 250V/500V/1000V | ±10% |
| 250V | 0.05MΩ~250MΩ | ±(5%+5) | |
| 500V | 0.05MΩ~500MΩ | ||
| 1000V | 0.05MΩ~1000MΩ | ||
| Short-Circuit Current | <2mA | √ | |
| Low Resistance Continuity(Ω) | Range | 0.00Ω~199Ω | ±(2%+5) |
| Test Current | 0.00~2Ω: >200mA | √ | |
| Line Impedance (Ω) | Range | 0.01Ω~2000Ω | ±(5%+5) |
| Operational Voltage(Freq.) | 195V~440V(45Hz~65Hz) | √ | |
| Test Current | 20A | √ | |
| PFC Range | 0KA~26KA | √ | |
| Loop Impedance (Ω) | Range | 0.01Ω~2000Ω | ±(5%+5) |
| Operational Voltage(Freq.) | 195V~253V(45Hz~65Hz) | √ | |
| Test Current | 20A | √ | |
| PFC Range | 0KA~26KA | √ | |
| Loop Impedance Without Tripping(Ω) | Range | 1.00Ω~~2000Ω | ±(5%+5) |
| Operational Voltage(Freq.) | 195V~253V(45Hz~65Hz) | √ | |
| Test Current | 15mA | √ | |
| PFC Range | 0KA~26KA | √ | |
| RCD | Operational Voltage(Freq.) | 195V~253V(45Hz~65Hz) | √ |
| Test Current | 10mA/30mA/100mA/300mA/500mA | ±10% | |
| Tripping Times | ×1/2 *I n Range:0ms~2000ms | ±(5%+5) | |
| ×1 *I n Range:0ms~300ms | |||
| ×1 *I n Range:0ms~500ms(Selective Countdown Function) | |||
| ×5 *I n Range:0ms~40ms | |||
| RCD Measurement RAMP Slope | Test Current Range | 10mA/30mA/100mA/300mA/500mA | ±10% |
| AC Voltage (V) | Range | 0V~440V | ±(5%+2) |
| Frequency Response | 45Hz~60Hz | √ | |
| Resolution | 1V | √ | |
| Features | |||
| Display Count | 9999 | ||
| Auto Power Off | √ | ||
| Low Battery Indication | √ | ||
| Data Logging | √ | ||
| LCD Backlight | √ | ||
| AUTO Half-wave Test | √ | ||
| RCD Countdown Measurement | 30 Seconds | √ | |
| RCD Half-wave Test | √ | ||
| Phase Switch (RCD) | 0°and 180° | √ | |
| General Characteristic | |||
| Power | 1.5V Batteries(LR6) X 6 | ||
| LCD Size | 125mm X 37mm | ||
| Product Color | Red and Grey | ||
| Product Net Weight | 1000g | ||
| Product Size | 210mm X 175mm X90 mm | ||
| Standard Accessories | Batteries, Test Lead (1 x Green, 1x Black, 1 x Red), Specialized Test Lead, Remote Control Test Lead | ||
| Standard Individual Packing | Gift Box, English Manual, Tool Box | ||
| Standard Quantity Per Carton | 4 PCs | ||
| Standard Carton Measurement | 510mm X 330mm X 300mm (0.051CBM Per Standard Carton) | ||
| Standard Carton Gross Weight | 15Kg | ||
We do not have MOQ, but we have MOV (Min order value) which is USD3000. If your order quantity is big enough, we will give you some discount.
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------
