Specifications
1.SZL-01 Lock Hole Slot Machine2.milling holes and grooves
3.Manufacturer
4.In Stock
SZL-01 Lock Hole Slot Machine
Equipment Features:
1. Used for milling holes and grooves of all types of lock-installation for aluminum doors
and windows.
2. It is made of the horizontal three-hole drill and vertical copy-routing mill.
3. The vertical location of the three-hole drill can be adjusted.
4. Colum-oriented guide is installed for the vertical movement of the three-hole drill
head, which ensured that three holes is parallel to the bottom.
Main Specification and Technical Parameter:
Power Supply |
380V 50Hz |
Motor Power |
1.85Kw |
Air Consumption |
3L/min |
Operation Air Pressure |
0.5~0.8Mpa |
Main Shaft Rotary Speed |
11200r/min 910r/min |
Blade Specification |
Φ5mm Φ8mm |
Copy-routing Range |
90mmX290mm |
Contour Dimension |
4050X1130X1500mm |
Weight |
300kgs |
