DSFX-18X20 Cover Milling For a Aluminum Plastic Doors and Windows

Specifications

1.DSFX-18X20 Cover Milling For a Aluminum Plastic Doors and Windows
2.Manufacturer
3.In stock

DSFX-18X20 Cover Milling For a Aluminum Plastic Doors and Windows



Equipment Features:



1. It is used for milling rabbet of rails-  matching for the plastic sliding window cover profiles and
    push pull frame profiles.



2. The tool is installed on the ends of the axis, with the features of easy replacement of tools
     and saving production cycle.



3. Adjustable guide plate, only the orientation width is adjusted when replacing the profiles
    types, and without need of replacing the guide plate, which can save reinvestment cost of the
    application of the equipment.







Main Specification and Technical Parameter:




Supply Power	380V 50Hz
Power	750Kw
Main Shaft Rotary Speed	2800r/min
Processing Scope	Φ130
Blade Specification	18mmX20mm
Contour Dimension	530X530X1100mm
Weight	100kgs
