Specifications
1.silicone sealant extruder2.Sealant Coating Machine is pure air power
2.Key parts used imported products to ensure reliabl
silicone sealant extruder/Sealant Coating Machine is used for insulating glass, glass curtain wall and other related field, the main features as below:
Two-component sealant coating machine
Max. air-consumption valume/0.5m3/min
Insulating Glass Processing Machine
Glass Machine/Equipment
GT04 Two-component sealant coating machine/Silicone Extruder/insulating glass machine /double glass machine /glass machine/machinery/equipment /glass windows machine /sealant spreading machine /sealant sealing machine /sealant coating machine
Pneumatic Silicone extruder Machine
1.Function Characters:
GT04 Two-componet sealant coating machine is absorbing the most excellent technology in the world. It is used on the seal connection of the hollow glass, wall glass and the others. A and B component glue pump are used hydraulic system and air driving system individually. They are controlled by non-electrical controlling system, the switch is very sensitive and reliable. It’s unique, convenient and adjustable proportion installation can assure the strictly proportion demand of the double component glues in the utmost possibility. The out-glue is equality, good effect and high efficiency.
2.Functions and Features:
1.It is composed of raw material pump, solidification pharmaceutical pump, proportional pump, sealant-mixture system, hydraulic pressure system, electric system and so on.
2. Raw material pump, solidification pharmaceutical pump and proportional pump adopt the special high-pressure filling pump and the materials can be supported equivalently in two-way. The raw material pump is compelled by the hydraulic pressure system while the solidification pharmaceutical pump is compelled by the pheumatic motor.
3.There are high-pressure valves in the underpart entrance of solidification
pharmaceutical filter and material-feeding place of the mixing device and one-way valve is set in the mixing device so as to prevent two-components from fleeing each other.
4.Rising and falling system is controlled by hand valve and the proportion of the two-components can be changed by adjusting the slipper in the swinging pole. Tightening the nut once the demanding scale is reached.
3.Technical Parameter:
Model |
GT04 |
Mix ratio |
6:1~14:1 |
Charging barrel |
200L |
Curing agent barrel |
20L |
Mix air consumption |
0.8m³/min |
Squeeze pressure |
29Mpa |
Air pressure |
0.5-0.8Mpa |
Total weight |
650kgs |
Outside dimension |
1100*950*2500mm |
4.Contact Information:
Celine
Jinan Bohman Machinery Co., Ltd.
Mobile:008615953180856
TEL:008653187501258
FAX:008653187568388
MSN OR MAIL BOX IS jinanbohman at hotmail com
