Windows and Doors Corner Connector Saw
US$ 1,000 - 5,500
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
Bohman
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CNC Control Aluminium Corner Crimping MachineUS$ 20,000 - 30,000MOQ: 1 Set -
Aluminum Curtain-wall Porfile Tenon Milling MachineUS$ 10,000 - 10,000MOQ: 1 Set
-
Aluminium Window Punching Manual Machine/Hydraulic Six-seat Pressing Machine for Aluminum Window and DoorUS$ 1,000 - 3,000MOQ: 1 Set
-
Aluminium Window Making Machine of Single Axis Copying RouterUS$ 1,000 - 4,000MOQ: 1 Set
-
4-axis Aluminium Profiles Machining Center With CNCUS$ 10,000 - 25,000MOQ: 1 Set
Condition
New
Place of Origin
Shandong, China
Brand Name
Bohman
Model Number
LJJA-500(450)
Voltage
380V 50HZ
Rated Power
2.2KW
Dimension(L*W*H)
5670*1770*1840
Weight
500KG
Certification
CE&ISO9001
Warranty
1 Year
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Windows and Doors Corner connector saw1.Cut the aluminum profiles
2.ISO9001&CE
3.Good services
Windows and Doors Corner connector saw
Instruction of the LJJB-450:
- Imported hard alloy sawblades
- Automatic material feeding system
- Adjustable clamping system in front, back, up and down direction
- Safe and reliable cutting
- Spraying cooling system
Equipment Features:
- It has features of easy operation, reliable performance, advanced technique and convenient maintenance.
- Used for cutting of the corner profiles for aluminum doors and windows.
- Adopting computer-controlled system, and with automation level.
- Imported carbide saw blade is of high cutting speed, accurate processing and high effciency.
- Linear bearing motion pair gave less resistance force and ensure high processing accuracy
- Adopting automatic feeding system for the feeding device, it is with features of stability and reliability, and high efficiency.
- Clamping and feeding process adopt pueumatic control; It is with features of convenient operation, reliability, and production efficiency.
- Once clamping can achieve continues cutting of six-meter corner profile.
- Control system with automatic counting function.
- The cutting length numbers will be saved automatically when cutting off electricity.
Main technical parameters:
| Power Supply | 380V 50Hz |
| Cutting Motor Power | 3kw |
| Motor Rotary Speed | 2840 r/min |
| Operation Air Pressure | 0.5-0.8 Mpa |
| Auto-feeding Length | 5-580 mmt |
| Air Consumption | 80 L/min |
| Cutting Length | no limit when selected manual mode |
| Blade Imput Speed | 0-3 m/min |
| Blade Specification | φ500*φ30*φ4.4 mm |
| Blade W&H | 140*140 mm |
| Cutting Profile Surface Plane | ≤0.1 mm |
| Cutting Surface Verticality | 0.1 mm |
| Cutting Surface Roughness | Ra12.5 μm |
| Contour Dimension | 5670*1770*1840 mm |
| Weight | 800 kg |
Company philosophy&After-sale services:
Customer needs is our direction,customer satisfaction is our service tent.Jian Bohman's Ki-Moon for your business.We have a professional after-sale services team,glad to serves you all the time.The best serves of pre-sale and after-sale from our company will give you a friendly cooperation.We sincerely looking forward to your cooperation.
Send Inquiry to This Supplier
Business Type
Manufacturer, Trading Company
Year Established
2007
Factory Size
5,000-10,000 square meters
Total Employees
101 - 200 People
