Help CenterAluminium Window Making Machine of Single Axis Copying Router
Related Products
-
4-axis Aluminium Profiles Machining Center With CNCUS$ 10,000 - 25,000MOQ: 1 Set -
CNC Double Mitre Saw for Aluminum ProfileUS$ 5,000 - 7,900MOQ: 1 Set
-
Aluinium CNC Control Double Miter Saw for Window and DoorUS$ 11,000 - 14,500MOQ: 1 Set
-
Aluminum & PVC Profile Cutting Machine Double Mitre Saw Supplier's ChoiceUS$ 4,900 - 12,000MOQ: 1 Set
-
Automatic End Milling MachineUS$ 8,000 - 12,000MOQ: 1 Set
Specifications
1.aluminium window making machine2.axis copying router is processing water slot, hardware hole and all groove
aluminium window making machine of axis copying router is used for processing water slot, pulley groove, lock-hole and all of groove of PVC and aluminum windows and doors. the main features as below:
1.The standard mold to control the size of the holes shapes, the milling scale is 1:1
2.Be equipped with high speedy copy routing milling head to ensure the milling precision
3.The double step copy-routing needle design suitable for different size of the holes
4.It can processing different grooves controlled through the ruler
Main specification and technical parameter
Input Power Source |
380V/50Hz |
Total Power |
0.55Kw |
Working Air Pressure |
0.4-0.6Mpa |
Air consumption |
30L/min |
Milling Cutter Diameter |
Φ5 Φ8mm |
Milling Cutter Rotated Speed |
12000r/min |
Copy-routing Range |
290mmX90mm |
Contour Dimension |
1000mmX870mmX1500mm |
Weight |
280kgs |
