Help CenterAluminium Window Punching Manual Machine/Hydraulic Six-seat Pressing Machine for Aluminum Window and Door
Related Products
-
Aluminum CNC Four-point Crimping MachineUS$ 10,400 - 10,521MOQ: 5 Sets -
Automatic Feeding End-milling Machine for Aluminum Doors and WindowsUS$ 1,200 - 2,000MOQ: 1 Set
-
Aluminum Window Lock-hole Processing MachineUS$ 1,000 - 3,000MOQ: 1 Set
-
LSF3-300*100 Lock Hole Slot Machine for Aluminum & PVC Win-doorsUS$ 1,000 - 2,500MOQ: 1 Set
-
Aluminum Win-door Lock-hole Processing Machine/aluminum and PVC Doors and WindowsUS$ 1,000 - 3,000MOQ: 1 Set
Specifications
1.aluminium window punching manual machine2.hydraulic six-seat pressing machine
3.aluminum and pvc wind-door machine
aluminium window punching manual machine of pressing machine, aluminum window making machine, machine for aluminum wire making, hydraulic six-seat pressing machine
Equipment Features
1. Used for installation of aluminum alloy windows and doors and the punching processing of aluminum profiles
2. Every combined punching mold matched with the equipment can finish multi punching processing and by changing processing position, various types of profiles can be processed
3. Disk worktable with six working position is equipped with six set dies. Each die is used at any time by the worktable rotating, which greatly increased the production efficiency
Main specification and technical parameter
Power supply |
380V/50Hz |
Motor Power |
1.5kw |
Capability of Oil Box |
20L |
Press nominal Pressure |
50KN |
Travel Times |
30/min |
Closin Height |
185mm |
Punching Travel |
30m |
Processing Deviation from Straightness |
±0.1mm |
Cutting surface roughness |
Ra12.5µm |
Model Size |
250mmx200mmx215mm |
Contour Dimension |
1100mmX1200mmX1700mm |
Any question please do not hesiste to contact with Celine 008615953180856
