Home > Manufacturing & Processing Machinery > Machine Tools > Lathe > Precison High Speed Turning Lathe Machine C6250C
US$ 8,000 - 12,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Horizontal
CNC or Not:
Normal
Payment & Shipping
Payment Methods:
Port of Shipment:
Any port in china
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Precision Horizontal High Speed Gap Bed Lathe GH-1440AUS$ 3,500 - 4,000MOQ: 1 Set -
High Quality Precision Gap Bed Lathe Machine GH-1440AUS$ 3,500 - 4,000MOQ: 1 Set
-
Precision Manual Gap Bed Lathe Machine GH-1440AUS$ 3,500 - 4,000MOQ: 1 Set
-
Precision Conventional Gap Bed Lathe Machine GH-1440AUS$ 3,500 - 4,000MOQ: 1 Set
-
Precision Horizontal High Speed Bench Lathe C0636AUS$ 3,500 - 4,000MOQ: 1 Set
Condition
New
Type
Horizontal
CNC or Not
Normal
Automatic Grade
Manual
Max. Swing Diameter
500mm, 660mm, 800mm
Place of Origin
Shandong, China
Brand Name
UNITECH
Model Number
500mm
Voltage
220V, 380V.
Power(W)
7.5KW
Dimension(L*W*H)
2950/3500/3950x1150x1780mm
Weight
2200, 3000kgs
Certification
CE, ISO9001
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
precison high speed turning lathe machinecan be with DRO high speed turning lathe
be with TTA precision turning lathe
| Model | CA6150 CA6250 | CA6166 CA6266 | CA6180 CA6280 | |||||
| CA6150B CA6250B | CA6166B CA6266B | CA6180B CA6280B | ||||||
| CA6150C CA6250C | CA6166C CA6266C | CA6180C CA6280C | ||||||
| Specifications | ||||||||
| Max .Swing over bed | 500mm | 660mm | 800mm | |||||
| Max .Swing over carriage | 300mm | 400mm | 540mm | |||||
| Max .Swing in gap | —— | 720mm | —— | 880mm | —— | 1020mm | ||
| Effective gap length | —— | 210mm | —— | 210mm | —— | 210mm | ||
| Max .length of work piece | 750/1000/1500/2000/2200/3000mm | 750/1000/1500/2000/2200/3000mm | 750/1000/1500/2000/2200/3000mm | |||||
| Width of bed | 400mm | 400mm | 400mm | |||||
| Section of turning tool | 25×25mm | 25×25mm | 25×25mm | |||||
| Spindle | Spindle speed | 10-1400rpm/16-1400rpm(24steps) | 10-1400rpm/16-1400rpm(24steps) | 10-1400rpm/16-1400rpm(24steps) | ||||
| Hole through spindle | 52mm ,(80mm),[105mm] | 52mm ,(80mm),[105mm] | 52mm ,(80mm),[105mm] | |||||
| Spindle taper | (MT6)(Φ90 1:20)[Φ113:20] | (MT6)(Φ90 1:20)[Φ113:20] | (MT6)(Φ90 1:20)[Φ113:20] | |||||
| Feed | No. of feed | (64 kinds)(for each) | (64 kinds)(for each) | (64 kinds)(for each) | ||||
| Range of metric threads | (1-192mm) (44 kinds) | (1-192mm) (44 kinds) | (1-192mm) (44 kinds) | |||||
| Range of inch threads | (1-24tpi) (21kinds) | (1-24tpi) (21kinds) | (1-24tpi) (21kinds) | |||||
| Range of module threads | 0.25-48 (module 39 kinds) | 0.25-48 (module 39 kinds) | 0.25-48 (module 39 kinds) | |||||
| Range of diametral pitc threads | 1-96DP (37 kinds) | 1-96DP (37 kinds) | 1-96DP (37 kinds) | |||||
| Tailstock | Max. tailstock spindle travel | 150mm | 150mm | 150mm | ||||
| Tailstock spindle diameter | 75mm | 75mm | 75mm | |||||
| Taper of tailstock spindle center hole | (MT5) | (MT5) | (MT5) | |||||
| Main motor | 7.5KW(10HP) | 7.5KW(10HP) | 7.5KW(10HP) | |||||
| Packing dimensions | Overall dimensions for 750mm | 2440×1140×1750 | 2440×1140×1750 | 2440×1140×1750 | ||||
| (L×W×H mm) | Overall dimensions for 1000mm | 2650×1140×1750 | 2650×1140×1750 | 2650×1140×1750 | ||||
| Overall dimensions for 1500mm | 3150×1140×1750 | 3150×1140×1750 | 3150×1140×1750 | |||||
| Overall dimensions for 2000mm | 3650×1140×1750 | 3650×1140×1750 | 3650×1140×1750 | |||||
| Overall dimensions for 2200mm | 4030×1140×1750 | 4030×1140×1750 | 4030×1140×1750 | |||||
| Overall dimensions for 3000mm | 4800×1140×1750 | 4800×1140×1750 | 4800×1140×1750 | |||||
| Overall dimensions for 4000mm | 4800×1140×1750 | 4800×1140×1750 | 4800×1140×1750 | |||||
| Weight(kg) | Length | G.W. N.W. | G.W. N.W. | G.W. N.W. | ||||
| Overall dimensions for 750mm | 2170 2060 | 2380 2260 | 2520 2400 | |||||
| Overall dimensions for 1000mm | 2260 2140 | 2570 2450 | 2720 2560 | |||||
| Overall dimensions for 1500mm | 2420 2290 | 2810 2640 | 2980 2800 | |||||
| Overall dimensions for 2000mm | 2790 2640 | 3050 2880 | 3260 3087 | |||||
| Overall dimensions for 2200mm | 2940 2790 | 3390 3180 | 3490 3287 | |||||
| Overall dimensions for 3000mm | 3450 3300 | 3930 3687 | 4220 3887 | |||||
| Overall dimensions for 4000mm | 3750 3600 | 4580 4200 | 4850 4500 | |||||
| Accessories: | ||||||||
| Standard accessories | Optional accessories | |||||||
| 3-jaw chuck | DRO | |||||||
| 4-jaw chuck | Quick change toolpost | |||||||
| Steady rest | Chuck protection | |||||||
| Follow rest | Leading screw guard | |||||||
| Foot plate | Toolpost protection | |||||||
