9V Battery Digital Multimeter With Back Light YT-0832
US$ 2.1 - 3.9
MOQ: 1200 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
YINTE
Model Number:
YT-0832
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo Shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Accuracy Digital Multimeter YT-0828US$ 2.1 - 3.9MOQ: 600 Pieces -
YINTE YT0831B LCD Digital MultimeterUS$ 2.3 - 4.7MOQ: 100 Pieces
-
100% Authentic AC/DC Portable Auto Ranging Digital Multimeter YT-0830 With CEUS$ 1.8 - 3.5MOQ: 600 Pieces
-
CE Certificated YT-0829 AC/DC Voltage Display Digital Multimeter Quality ChoiceUS$ 2.2 - 5.1MOQ: 1 Piece
-
YT-0827 AC/DC Voltage Resistance LCD Display Digital Multimeter With CEUS$ 3.7 - 5.6MOQ: 1 Piece
Place of Origin
Zhejiang, China
Brand Name
YINTE
Model Number
YT-0832
Measuring Current Range
2m-20A
Measuring Voltage Range
200m-1000V
Measuring Resistance Range
200/2k/20k/200kΩ
Measuring Inductance Range
200μ-2m
Operating Temperature
usual condition
Dimensions
85*185*30mm
Specifications
multimeter with back light YT-0832DC voltage: 200m/2/20/1000v
Alternating voltage:200/750v
MOQ:600PCS
WITH CE
digital multimeter with back light YT-0832
| Model | YT-0832 |
| DC voltage | 200m/2/20/200/1000v |
| Alternating voltage | 200/750v |
| Direct current | 200μ/2m/20m/200m/20A |
| Resistance | 200/2k/20k/200kΩ |
| Make-and-break test | √ |
| LED test | √ |
| Transistor test | Vce≈3V,1b≈10?A |
| Diode test | 2.8V/1mA |
| Battery | 9V (NEDA 6F22)×1 |
| Dimension | 85*185*30mm |
| Package | 640*460*465mm |
| G.W./N.W. | 33/32KGS |
Accessories
Instruction, 9V(6F22) baterry*1, multimeter pencil
3 ½ LCD
Max. reading: 1999
Low voltage indication
Overload protection
Make-and-break function test
Safety class CAT 600V
The body case used the material of insulated ABS, ensure the shell provide credible insulation.
