Digital Voltmeter Ohmmeter Ammeter Multimeter YT-0828B
Negotiable
MOQ: 504 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
YINTE
Model Number:
YT-0828
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Digital Voltmeter Ohmmeter Ammeter Multimeter YT-0828DNegotiableMOQ: 504 Pieces -
Portable AC DC Voltage LCD Digital Clamp Multimeter Electronic Tester Meter YT-0863NegotiableMOQ: 500 Pieces
-
Portable AC DC Voltage LCD Digital Multimeter YT-0827NegotiableMOQ: 500 Pieces
-
High Precision LCD Display Digital Multimeter YT-0829US$ 0.9 - 5MOQ: 1200 Pieces
-
High Grade Digital Multimeter YT-0830US$ 1.5 - 3.9MOQ: 1200 Pieces
Place of Origin
Zhejiang, China
Brand Name
YINTE
Model Number
YT-0828
Measuring Current Range
2M/20A
Measuring Voltage Range
200M/1000V
Measuring Resistance Range
200Ω-20KΩ
Operating Temperature
0-50°C
Dimensions
200*90*40MM
Specifications
Digital Voltmeter Ohmmeter YT-0828B1) Easily operated
2) Plug-in insulation tester
3) AC/DC current and voltage test
Digital Voltmeter Ohmmeter Ammeter Multimeter YT-0828B
1. 3 1/2 digits large LCD display with maximum reading of 1999
2. Versatility of use with AC/DC voltage and resistance measurement
3. Data hold for easy reading (Clamp Meter)
3. Plug-in insulation tester adapter 500VCD(optional)
4. Audible continuity
5. Low power indication
| Function | Range | Accuracy |
| DC Voltage | 1000V | ±(0.5%+1dgt) |
| AC Voltage | 750V | ±(1.2%+4dgt) |
| AC Current | 200A-1000A | ±(2.5%+5dgt) |
| Resistance | 200Ω-20KΩ | ±(1.0%+2dgt) |
| Continuity Buzzer | Yes | |
| Display Hold | Yes | |
| Power Supply | 9V Battery 6F22 | |
| Maximum Display | 1999 | |
| Display Size | 14×47mm | |
| Product Net Weight | about 350g | |
| Products Size | 200*90*40mm | |
| Clamp color available | yellow | |
| Standard Accessories |
Test Lead, Battery, Manual, Holster
|
|
| Special Function | |
| Special Function | DM6016A |
| Diode test | √ |
| Continuity buzzer | √ |
| Low battery indication | √ |
| Hold | Data hold |
| Auto power off | √ |
| Function protection | √ |
| Input impedance | 10Ω |
| Sampling rate | 3 times/s |
| AC Frequency response | 40~150Hz |
| Operation way | Auto range |
| Clamp size | 35mm |
| Power | 9V (6F22) |
Item NO. |
Digital Clamp Meter YT-0864 |
| Jaw max mouth | 50mm |
| Outer size | 200*90*40mm |
| Weight/pcs | 370G(Including battery) |
| Package | Each one in color box, 36pcs/ctn |
| N.W/CTN | 20kgs |
| G.W/CTN | 23kgs |
| Carton Size | 63*24*48.5cm |
