DT830 New 7 Functions AC DC Voltage Electrial Digital Voltage Tester

DT830 New 7 Functions AC DC Voltage Electrial Digital Voltage Tester photo-1
Negotiable MOQ: 120 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
YINTE
Model Number:
DT0830
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Zhejiang, China
Brand Name YINTE
Model Number DT0830
Measuring Current Range 200-10A
Measuring Voltage Range 1000V
Measuring Resistance Range 200Ω-2000KΩ
Measuring Capacitance Range AC DC voltage electrial multimeter
Measuring Inductance Range AC DC voltage electrial multimeter
Operating Temperature 0-50°C
Dimensions 126*70*26mm



Product Description



DT830  new 7 functions AC DC voltage electrial  Digital Voltage Tester

1.  3 1/2 digits large LCD display with maximum reading of 1999

2.  Versatility of use with AC/DC voltage and resistance measurement

3. 7 kinds measurement pattern

4. 19 ranges

5. battery under voltage remind

6. outrange overload preotection

7. Low power indication

Technical Specifications



Function Range Accuracy
Material 100% new ABS, no reclyed
DC Voltage 200m/2000m/20/200/1000V ±0.8%
AC Voltage 200/750V ±1.5%
AC Current 200μA/2000μ/20m/200m/10A ±1.2%
Resistance 200/2000/20k/2000KΩ ±1.0%
Temperature -20 to 1000 °C ±2.0%
Low battery indication Yes
Auto power off Yes
Function protection Yes
Diode test ok
Audion ok
Operation way Auto range
Power Supply 9V Battery 6F22
Maximum Display 1999
Display Size 14×47mm
Product Net Weight about 98g
Products Size 126×70×26mm
Clamp color available yellow, black, green, blue,orange
Standard Accessories

Test Lead, 9V(6F22)Battery, Instruction Manual









Packaging & Shipping

Item NO.

YT-0830 new 7 functions AC DC voltage electrial  Digital Voltage Tester
Outer size 126*70*26MM
Weight/pcs 98G(Including battery)
Package Each one in singal blister card or each one gift box, 5pcs/inner box,60pcs/ctn
N.W/CTN 9.5kgs
G.W/CTN 11.5kgs
Carton Size 47*23*56cm
MOQ 120PCS in YINTE brand name, 600pcs in OEM brand name
Sample time 2-5days, depends on product style and shipping
Sample fee free
Freight charge paid by customer, prepaid
Delivery time according to the order quantity
Payment terms TT, Western union, paypal,etc.
