ELD-5 Inductive Straight-line Trip Displacement Sensor Position Sensor

*1

High precision,close tolerance

*2

smooth moving,long expected life

*3

springback self-resetting zero setting range2,5,10,20,50...1000mm

Model

10L           25L            50L         75L           100L

Linear stroke ( mm )

10mm        25 mm         50 mm       75 mm        100 mm

Shelly Length ( A )

48            63             88           113           138

Mechanical Stroke ( B )

15            30             55           80            105

Size( C)

7            12             12           12             12

Size( D )

6            32             32           32             32

  0.25%        0.2%           0.15%        0.1%          0.075%

Force

≤ 5N

0.002mm

4~20mA,0~5V  0~10V or  0~±5V, 0~±10V

9V,12V,15V,24VDC (Standard)

-30~100°C

Shock

5~20000Hz

50g

IP40
