Specifications
1.ELD-4 Position Sensor2.Moving head operating agility
3.Long life span,
4.high precision,
5.resisting shock
ELD-4 Position Sensor
ELD-3 displacement sensor offer a range of electrical strokes
from 5mm to 6000mm with resolution better than 0.01mm and linearities
as low as 0.01%. ELP-3 displacement transducer employing conductive
plastic resistance and collector tracks provide direct means of measurement
in control and regulation systems and in instrumentation.
Model |
75 L 100 L 150 L 225 L 300 L 360 L 450 L 500 L 600 L 750 L |
Linear Stroke ( mm ) |
75 L 100 L 150 L 225 L 300 L 360 L 450 L 500 L 600 L 750 L |
|
Shelly Length ( A ) |
201 227 277 354 430 505 619 684 810 994 |
Mechanical Stroke ( B ) |
79 105 155 231 307 368 460 510 612 764 |
Size( C) |
247 273 323 400 476 551 665 730 856 1040 |
|
Mechanical stroke ( mm ) |
76 102 152 228 304 366 457 508 610 762 |
Comprehensive Precision |
0.1% 0.1% 0.08% 0.07% 0.06% 0.05% 0.05% 0.05% 0.05% 0.04% |
Repeatability |
< 0.01mm |
Output Signal |
4~20mA,0~5V 0~10V or 0~±5V, 0~±10V |
Power Voltage |
9V,12V,15V,24VDC |
Operational Temperature |
-30~100°C |
Vibration |
5~20000Hz |
speed |
5m/s |
Protection grade |
IP65 |
