New Security System EAS AM Antenna XST-AM04

Specifications

EAS AM Antenna
1.EAS AM security system
2.largest detection range in line
3.Low false alarm rate
4.DSP,ASC&DMFD technology

New Security  Sytem EAS AM Antenna   XST-AM04

 EAS AM Antenna ,EAS Antenna , EAS System, Security System

Features:

             XST-AM04 is a new generation of SMA intelligent advanced EAS system. It USES advanced DSP + FPGA digital technologies and  the unique intelligent label identify algorithm, as well as new electricity-saving circuit design, alternating magnetic field incentive technology etc.The high density PMMA(artificial crystal) materials and graceful industrial design model are the highest level of advanced  AM Antennas. The advanced EAS systems detection system are widely used in high-grade dress clothing, cosmetic shops, pharmacy, 3C products stores commodities such as security management.



•  Low power consumption (average 220VAC) 150mA,110 V/AC

• The latest label identify algorithm

•  Advanced DSP + FPGA digital processing technology
•  Alternating magnetic field design, reducing detection blind spots
•  Easy Assembly and debug
•  Don't need any special external synchronizer
• The auto/hand-switch synchronous parameter setting function
•  The auto/hand-switch testing parameter setting function
•  Integrated  sound and light alarm
•  Apply to all 58kHz sound magnetic soft Tags and hard tags



parameters:

Antenna

Material	PMMA
Input voltage	220V AC or 110V AC
Dimension	150x38x13cm
PMMA borad	129.5*38*2.5cm
Packing	168*48*14CM
Weight	25kg
Frequency	58KHz



Controller

Freq.	58KHz
Size	38.5X34.5X18.5cm
G.W.	3.2KG





PS:

1.The antenna should work with the a controller.

2.A controller can control three pieces of Antenna.







Update Date:2011-7-29 19:43:37
