Maquet Servo I Adult ventilator Resuscitation ventilator flexibility, efficiency and ease of training inspiratory/expiratory

Specifications

Cost-efficiency
A system that's as functional as your needs
Automode
CO2 Analyzer
NIV

Features:



Cost-efficiency: making your investment go further

• The modular design of SERVO-i, together with its simplified cleaning and maintenance procedures and easy upgradeability, ensure that you have a system that is right for your needs, both today and in the future.
• Treat all patients from a single system: SERVO-i Adult can be upgraded to Universal doing away with the need for different ventilators by patient type.
• Key parameters in SERVO-i design include the need to provide greater flexibility in patient treatment in order to speed the weaning process, and streamlined operating costs.



A system that's as functional as your needs

• SERVO-i is designed for flexibility, efficiency and ease of training, operation and maintenance to meet hospital needs.

Comprehensive monitoring capabilities

• SERVO-i monitors a number of alternative waveforms such as Pressure, Flow, Volume and CO₂.
• The additional calculations of lung mechanics parameters include: total PEEP; static and dynamic compliance; inspiratory/expiratory resistance; Shallow Breathing Index; Time Constant; Work of Breathing; and P 0.1.

Ventilation Record Card

• The ventilation Record Card is the perfect tool for a clinician to facilitate research work and presentations.

SERVO-i Ventilation modes

• The typical ICU must be able to cope with any combination of patient and clinical situations at all times. SERVO-i features a range of ventilator modes for different treatment scenarios.
• A comprehensive array of tools assists the clinician who is interested in investigating many treatment options that promote lung protection and patient interaction.

Automode

• The Automode option allows patient interaction. Set a controlled mode and let the ventilator adapt to the current patient situation, switching between controlled and supported breathing in connection with patient effort. The control mode is initiated after an operator set time-out. This well-established mode provides smoother, safer patient transition, documented shorter weaning times, and less staff intervention.

Open Lung Tool

• The Open Lung Tool provides an instrument for effectively determining the effect of a ventilator intervention and includes the following features:
• A long-term breath-by-breath trend of vital parameters for evaluating the patient response to an intervention.
• Identification of patients unlikely to benefit from a recruitment maneuver at a point in time or position.
• Guidance and standardization for a successful recruitment maneuver.
• The dynamic compliance and carbon dioxide excretion will give a quality assessment of the effect any intervention has on the lung.

CO₂ Analyzer

• End tidal carbon dioxide measurement may give important insight into the efficiency of the ventilation. The minute production of CO₂ will give a reliable indication of the patient’s metabolic load.
• CO₂ can also be used as an indication of cardiac depression, which is especially helpful during recruitment maneuvers where high transpulmonary pressure may induce a fall in preload and Cardiac Output.

NIV

• The easy-to-use NIV option for infants and adults provide responsive and comfortable leakage compensation made possible by measuring and adjusting during the same breath, thus maintaining the set pressure to the patient.
• A waiting position from standby to start ventilation facilitate the work for the staff and increases patient comfort.
• The monitoring capabilities of the SERVO-i will enhance patient surveillance and guarantee smooth liberation from the ventilator.

Y-sensor measurement

• This enables measurement of pressure and flow as close to the patient’s airway as possible.
• Based on fixed orifice technology, the sensor is small and gives a very low contribution to dead space volume (typically 0.75 ml for the neonatal/pediatric sensor).
• Y Sensors are available for neonatal/pediatric and adult patients.



SERVO-i accessories & consumables

• MAQUET ventilator accessories and consumables are fully tested and designed to work optimally with SERVO ventilators.
• Only accessories approved and distributed by MAQUET ensure that the system works to SERVO performance standards for optimal patient care.

Technical Data

General information

• Dimensions: Patient Unit W 300 x D 205 x H415 mm
• User Interface: W 355 x D53 x H 295 mm
• Weight: approx 20 kg (Patient Unit 15 kg, User Interface 5 kg)
